Muto Premium XL150/80/120
Muto Comfort L80
Fixed Panel ONLY -
Ceiling mount
Installation instructions
936020 – 05-2018
| EN |

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Muto Premium XL150 and is the answer not in the manual?

Questions and answers

Summary of Contents for Dormakaba Muto Premium XL150

  • Page 1 Muto Premium XL150/80/120 Muto Comfort L80 Fixed Panel ONLY - Ceiling mount Installation instructions 936020 – 05-2018 | EN |...
  • Page 2: Table Of Contents

    MUTO Premium XL150/80/120 / MUTO Comfort L80 Table of Contents Fixed Panel Installation Instructions Table of contents 1  Technical specifications Overview 1.1.1 General information 1.1.2 Intended use 1.1.3 Glass requirements and fittings 1.1.4 Requirements for glass panel 1.1.5 Safety instructions 1.1.6 Symbols used - Safety/Installation...
  • Page 3: Technical Specifications

    MUTO Premium XL150/80/120 / MUTO Comfort L80 Technical specifications Fixed Panel Installation Instructions 1  Technical specifications Overview • Only properly qualified and specially trained staff are authorized to mount dormakaba glass These instructions are for installation of MUTO hardware.
  • Page 4: Tempered Laminate Glass (Tlg) And Adhesive Specifications

    MUTO Premium XL150/80/120 / MUTO Comfort L80 Technical specifications Fixed Panel Installation Instructions Tempered laminate glass (TLG) and adhesive specifications Required parts for laminate glass Part Number Quantity Usage recommendation with MUTO System (not included) 3M™ Scotch-Weld™ Urethane 934.800...
  • Page 5: Installation Instructions

    MUTO Premium XL150/80/120 / MUTO Comfort L80 Overall Fixed Panel Installation Instructions 2 Installation instructions Overall MUTO Premium/Comfort Fixed Panel 936020 05-2018...
  • Page 6: Securing Gasket To Track

    MUTO Premium XL150/80/120 / MUTO Comfort L80 Sidelite gasket Fixed Panel Installation Instructions Securing gasket to track Fig. 1 Sidelite gasket Track Sidelite Adhesive glass gasket 2.2.1 Ensure track is cut to proper length. 2.2.2 Cut adhesive gasket equal to track length.
  • Page 7: Secure Sidelite Section Profile To Track And Mounting Surface

    MUTO Premium XL150/80/120 / MUTO Comfort L80 Track Fixed Panel Installation Instructions Secure sidelite section profile to track and mounting surface Fig. 2 MUTO ceiling mount track Track Sidelite section profile 2.3.3 Ensure track is properly level and secure it to the 2.3.1 Align sidelite profile screw slot with track profile...
  • Page 8: Door/Wall Dimensions

    MUTO Premium XL150/80/120 / MUTO Comfort L80 Technical specifications Fixed Panel Installation Instructions Door/wall dimensions Sidelite mount: XL150/XL80/L80 Back of track to center 7/8" of mounting hole [23] in track (FPW) (FPW) Sidelite Sidelite glass glass 1/4" 1/2" [13]...
  • Page 9: Installing U-Channel For Sidelite

    MUTO Premium XL150/80/120 / MUTO Comfort L80 U-channel Fixed Panel Installation Instructions Sidelite glass Installing U-channel for sidelite Fig. 3 U-channel U-channel U-channel gasket Orient gasket(s) as shown. NOTE: Ensure U-channel is plumb and the back of the 2.5.1 Install gaskets as shown. Trim to correct length.
  • Page 10: Installing Sidelite Glass Gasket

    MUTO Premium XL150/80/120 / MUTO Comfort L80 Sidelite gasket Fixed Panel Installation Instructions Cover clips Installing sidelite glass gasket Fig. 5 Sidelite gasket Sidelite profile Sidelite Sidelite glass gasket Sidelite location gasket 2.7.1 Cut gasket to length. 2.7.2 Press gasket in between sidelite glass and sidelite profile.
  • Page 11: Install View Protection Clips

    MUTO Premium XL150/80/120 / MUTO Comfort L80 View protection clips Fixed Panel Installation Instructions Cover spacers Install view protection clips Fig. 7 View protection clips TO BE USED WITH ONE OR MULTIPLE SIDELITE APPLICATIONS. Sidelite glass Sidelite glass View...
  • Page 12: Install Cover And View Protection Profile

    MUTO Premium XL150/80/120 / MUTO Comfort L80 Cover Fixed Panel Installation Instructions View protection profile End caps 2.11 Install cover and view protection profile Fig. 9 Cover and profile Cover clip Cover Cover View protection clip and profile removed for...
  • Page 13 DORMA USA, Inc. 1 Dorma Drive, Drawer AC Reamstown, PA 17567 T: 717-336-3881 F: 717-336-2106 www.dormakaba.com...
