Summary of Contents for Contemporary Research ICE-HE
- Page 1 Product Manual Ethernet Head-End Controller Version 3.5 February 8, 2016 4355 Excel Pkwy, Suite 600, Addison, TX, 75001 Phone:972-931-2728 • Toll-Free: 888-972-2728 • Fax: 972-931-2765 • Website: www.crwww.com E-Mail: Sales@crwww.com...
-
Page 2: Table Of Contents
RS-232 HE Commands ........................13 iC-Net SmartZones ..........................14 System Map ............................15 Typical RF and ICC-Net Signal Flow ....................16 Safety Instructions ........................... 17 Limited Warranty and Disclaimer ..................... 18 RF Channel Frequencies ........................19 Contemporary Research ICE-HE Ethernet Head End... -
Page 3: Overview
TV and video projectors across a facility or campus. The ICE-HE typically distributes 1-way control over RF, operating in the gap between channels 4 and 5, without interfering with any other channel. 2-way control is available for legacy systems. -
Page 4: Specifications
White button sends press and release RS-232 response to PC software or control system Emergency: Red button sends press and release RS-232 response to PC software or control system Ethernet RX/TX: Yellow LEDs indicate Ethernet data send and receive Contemporary Research ICE-HE Ethernet Head End... -
Page 5: Control Connections
F’, female, 75 ohm impedance, RF to CATV distribution to controllers Data Transmit: Mid-band VHF, 74.7 MHz, narrow-band signal between channels 4 and 5 ± 80 KHz max carrier deviation +55 dBmV maximum (default) Contemporary Research ICE-HE Ethernet Head End... -
Page 6: Icw-Net Connections
11 to 18 VDC, 12 VDC typical, 300 mA maximum (may be unregulated) UL/CSA listed wall power supply (included for domestic 110 VAC/60 Hz shipments only) Includes 10 dB RF attenuator 12 VDC Power Supply Contemporary Research ICE-HE Ethernet Head End... -
Page 7: Installation - 1-Way
2x1 video switcher or other device. 3. You’ll have to choose application – the ports act as either an output or input, not both. See Control Connections on page 5 for wiring and rating information. Contemporary Research ICE-HE Ethernet Head End... -
Page 8: Installation - 2-Way
RF Out signal to the other CATV sources. Limit RF Out adjustment to -10 dB, using attenuators to achieve a lower signal strength. 4. Add a Sub-CATV Diplexer after the CATV amplifier. 5. Connect the Sub-Channel output of the Diplexer to the HE RF In connection . Contemporary Research ICE-HE Ethernet Head End... -
Page 9: Ethernet Setup
Reset IP Address If you change the default address and forget what it is later on, you can always reset the ICE-HE back to the default settings using the unit’s front-panel DIP switch 2. While the power is on, flip the switch off, then back on to reset the IP address. -
Page 10: Rs-232/Telnet He Commands
RF levels. RF Output Displays RF output level Example Response: AO 5000* (Full Output) DIP Setting Displays DIP switch setting in binary format Example Response: AS 222* (Switches 1 and 6 off) Contemporary Research ICE-HE Ethernet Head End... - Page 11 IG = Returns current MAC address, Ethernet firmware version, current IP information IG = xxx.xxx.xxx.xxx Defines IP gateway, then sends status IM Subnet IM = Returns current MAC address, Ethernet firmware version, current IP information IM = xxx.xxx.xxx.xxx Defines IP subnet mask, then sends status Contemporary Research ICE-HE Ethernet Head End...
-
Page 12: Rs-232 Icc-Net Control Protocol
[ ] brackets Commas separate the bytes, but are not part of the protocol Double quotes enclose the command string, but are not part of the protocol Contemporary Research ICE-HE Ethernet Head End... -
Page 13: Rs-232 He Commands
Tip: If the number of present and expected devices match, the green Net LED on the HE will blink once per second. If the two numbers do not agree, the LED blinks twice per second. Contemporary Research ICE-HE Ethernet Head End... -
Page 14: Ic-Net Smartzones
Tip:You've probably figured out that you never want to assign a virtual device number to an actual device in the system. If you assigned #1536 to a device, all the TV controllers in Zone 6 would respond every time you sent a command to that one device. Contemporary Research ICE-HE Ethernet Head End... -
Page 15: System Map
W252 Hallways 1792 W253 1793 W254 1794 Floor 1795 E151 1796 2048 E152 Office E153 Admin 2049 E154 A/V Center 2050 1024 4095 Floor All Zones E251 1025 E252 1024 E253 1025 E254 1026 Contemporary Research ICE-HE Ethernet Head End... -
Page 16: Typical Rf And Icc-Net Signal Flow
This diagram shows the structure of a typical Contemporary Research media retrieval system. This includes the components for 2-way control – Display Express systems are one-way. Contemporary Research ICE-HE Ethernet Head End... -
Page 17: Safety Instructions
Contemporary Research ICE-HE Ethernet Head End... -
Page 18: Limited Warranty And Disclaimer
Contemporary Research Corporation (CR) warrants this product to be free from defects in material and workmanship under normal use for a period of two years from the date of purchase from CR. Should such a defect occur CR will repair or replace, at their option, the defective product at no cost for parts or labor. -
Page 19: Rf Channel Frequencies
HRC/IRC — About 10% of CATV systems use these alternate frequency plans, created to reduce “beat” interference. FCC – U.S. Broadcast VHF/UHF *Channel 1 — IRC/HRC spacing created a Channel 1 between 4 and 5, the rarely used channel must be shifted to different frequency for IC-Net operation Contemporary Research ICE-HE Ethernet Head End...
