- Page 1 Product Manual QIP™ IPTV Encoders June, 2018 4355 Excel Pkwy, Suite 600, Addison, TX, 75001 Phone: 972-931-2728 • Toll-Free: 888-972-2728 • Fax: 972-931-2765 E-Mail: Support@crwww.com Website: http://www.contemporaryresearch.com Contemporary Research QIP IPTV Encoders...
-
Page 2: Table Of Contents
RKU Universal Rack Mount Kit ......................13 The software included in this product contains copyrighted software that is licensed under the GPL. You may obtain the complete Corresponding Source code from us. Request license and version info by contacting Contemporary Research, contemporaryresearch.com/contact/contact-us/. -
Page 3: Overview
There are three QIP models that support a mix of HDMI, SDI, Component and Composite inputs – allowing a wide choice of sources using one or two QIP encoders in one rack space. QIP-HDMI 2 - Two HDMI inputs (unencrypted) QIP-YPB 2 - Two Component YPbPr inputs... -
Page 4: Video And Audio Assignment
✓ ✓ ✓ ✓ ✓ ✓ RGBHV Video 1 ✓ ✓ ✓ Video 1 ✓ ✓ ✓ Video 2 ✓ ✓ ✓ ✓ Video 2 No audio or caption restrictions No audio or caption restrictions Contemporary Research QIP IPTV Encoders... -
Page 5: Installation Overview
Resetting power will reset all system components without changing settings • Pressing Left and Right arrows during power-up resets to custom AV settings (see Advanced menu page). • Pressing Up and Down during power-up clears everything, resets to factory settings – use with caution Contemporary Research QIP IPTV Encoders... -
Page 6: Installation - Settings
Installation - Settings The following menus are the same for all QIP IPTV Encoders. We will base the examples on the QIP-HDMI 2, the unique video and audio input selections are noted on Page 4. • Front Panel. Press the SETUP button use the Up/Down buttons to move through menus, Left/Right to change settings, then press SELECT to store the changes at each step. -
Page 7: Program A And Program B
Program A and Program B There are two separate menus for Program A and B (examples below for the QIP-HDMI 2) Encoder Settings Sets video and audio properties for the program Video Input Select the video input (Program B adds the option to select NONE) -
Page 8: Common
Create unique name for the QIP QMOD* Version Starts with current version, use left and right arrows for versions of all software modules *At present, a few settings use QMOD as both encoders share similar menus. Contemporary Research QIP IPTV Encoders... -
Page 9: Advanced
Custom Reset – saves current settings to use for Reset Reset Select Factory Default or Custom settings IP Speed Auto | 100 Mbps Reboot Left or Right arrow cycles between Reboot, AV Dropped, FIFO Full counts, reset from Web page Contemporary Research QIP IPTV Encoders... -
Page 10: Web Pages
XP SP3 through Windows 10. When launched, it will automatically search and connect Contemporary Research devices over IP or USB. For QMOD and QIP encoders, CR Toolbox will present a list of found units. A user can click on a name and view the unit’s Web page or select one or more units for a firmware upgrade. -
Page 11: Using Vlc Media Player To Test Streaming
Multicast IP addresses range from 224.0.0.1 through 239.255.255.255, which are set aside for multicast streams. However, there are "reserved" combinations in that range that won't work efficiently, so you'll want to use addresses assigned by the IT department. Typical "non-reserved" addresses include: 239.0.0.5 239.0.100.99 239.3.0.1 Contemporary Research QIP IPTV Encoders... -
Page 12: Specifications
PS12-2 Switching power supply, 2A 12 VDC, standard cable for AC power strips PS12-8Y 8A power supply with Y cable to drive 2-4 QIPs (free at time of order) Options RK1 Single Rack Kit , RK2EZ Dual Rack Kit Contemporary Research QIP IPTV Encoders... -
Page 13: Rku Universal Rack Mount Kit
Add the rack mounts to the sides using the six 8-32 x 1/4" screws. Single Unit Rack Mounting Attach a long and short rack ear to each side at the front of the unit, using five of the 8-32 x 1/4" screws. Contemporary Research QIP IPTV Encoders... - Page 14 Research SSV-DX Display Express PC product carries a six month limited warranty. Product Service: Contemporary Research will test, repair, or replace the product or products without charge if the unit is under warranty. If the product is out of warranty, Contemporary Research will test, and then repair the product or products. The parts and labor charge will be estimated by a technician and confirmed by the customer prior to repair.
