Contemporary Research VSCC Dimensions

3.35
Video Out S-Video Out
1.125
UNLESS OTHERWISE SPECIFIED:
DECIMAL DIMENSIONS INCLUDING HOLES
FRACTIONAL DIMENSIONS INCLUDING HOLES
ANGLES
SURFACE FLATNESS .003 TIR PER LINEAR INCH.
ALL DIMENSIONS IN INCHES.
DO NOT SCALE THIS DRAWING.
5.50
Contemporary
Research
CR System Tools
CC
VSCC
S-Video Closed Caption Decoder
Caption/Control
Video In Settings
TOP VIEW
1 2 3 4
XX .010
.005
XXX
1/64
1
12 VDC Pwr In
100 mA max
Control Port Pwr
5 4 3 2 1 LED ( ) ( )
( ) ( )
SYM ECO NO. DESCRIPTION
**** REVISIONS ****
DRAWN DATE
Contemporary
RSH 01/30/04
Research
CHECKED DATE
TITLE PRODUCT DRAWING
CST-VSCC
APPROVED DATE
VIDEO TO S-VIDEO W/ CAPTIONING
SCALE
NONE
RELEASED DATE
SHT OF
1 1
DIR FILE
CST-VSCC_PD.DWG
TOP
DATE APPR.
DWG. NO.
950-5051
