51000-600 / 51000-601
Wireless Combination Smoke, Heat and
Carbon Monoxide Detector
Installation Guide
ATTENTION: This manual should be read prior to use and retained for further
information.
1. GENERAL INFORMATION
The Wireless Combination Smoke, Heat and Carbon Monoxide Detector is a
2xCR123A battery powered wireless detector intended for use with a compatible
wireless alarm system. The detector consists of a photoelectric smoke sensor,
thermistor heat sensor and electrochemical carbon monoxide sensor coupled to a
wireless transmitter, which communicates with the control panel. When fire or
carbon monoxide is detected, the detector sounds a loud local alarm and the built-
in transmitter sends a signal to the control panel. The Wireless Combination
Smoke, Heat and Carbon Monoxide Detector contains an integrated fixed 41°F
(5°C) temperature freeze sensor that will send a warning signal based on
temperature detected. This detector is designed to provide protection with 70-foot
spacing capability. The detector can send alarm, tamper and battery condition
messages to the system's receiver. Refer to the wireless system's instruction for the
maximum number of transmitters that can be supported.
The detector has an operational life of 10 years. After 10 years of operation the
detector will provide audio visual trouble indication and must be replaced.
WARNING: This product is intended for use in ordinary indoor residential areas. It
is not designed to measure compliance with Occupational Safety & Health
Administration (OSHA) commercial and industrial standards.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Apollo 51000-600
Summary of Contents for Apollo 51000-600
- Page 1 WARNING: This product is intended for use in ordinary indoor residential areas. It is not designed to measure compliance with Occupational Safety & Health Administration (OSHA) commercial and industrial standards. 51000-600 / 51000-601 Wireless Combination Smoke, Heat and Carbon Monoxide Detector...
- Page 2 2. DETECTOR OVERVIEW 2.2 DETECTOR BACK 2.1 DETECTOR FRONT Anti-Tamper Lock Mechanism CO Test Button CO Sensor Gas Entry Port Indicator LEDs Fire Test Button Battery Tamper Switch Compartment Mechanism Anti-Tamper Lock Release Figure 2 - Detector Back Sounder Figure 1 - Detector Front...
-
Page 3: Operation
2.3 DETECTOR MOUNTING BASE 4. OPERATION The Wireless Combination Smoke, Heat and Carbon Monoxide Detector contains a sounder which generates ANSI S3.41 Temporal-3 pattern when fire is detected or Tamper Switch ANSI S3.42 Temporal-4 pattern when Carbon Monoxide is detected. In alarm, a Mechanism message is also sent to the control panel and the detector’s ID is displayed. -
Page 4: Low Battery Detection
1 YELLOW 1 YELLOW A sensor has failed or flash flash followed General Fault some other fault has Chirp every 48 seconds The detector has every 4 occurred Tamper been removed from None seconds 1 GREEN flash the base every 12 The CO cell has seconds reached the end of its... -
Page 5: Battery Replacement
5. BATTERY INSTALLATION AND REPLACEMENT 6. PROGRAMMING TO CONTROL PANEL Refer to the appropriate compatible control panel programming guide for the 5.1 FIRST DETECTOR USE proper procedure required to enroll the Wireless Combination Smoke, Heat and The detector ships with batteries installed and a pull tab to prevent electrical Carbon Monoxide Detector into the system. - Page 6 • Next to a door or window that would be affected by drafts i.e. extractor fan or air vent • Outside • Do not install in any environment that does not comply with the detector’s environmental specifications • In or below a cupboard •...
- Page 7 Figure 10 - Example of proper mounting for detectors with sloped ceilings Figure 8 - Split level arrangement Figure 11 - Example of proper mounting for detectors with peaked ceilings Figure 9 - Example of proper mounting for detectors...
-
Page 8: Mounting Procedure
7.2 RECOMMENDED LOCATIONS FOR CARBON MONOXIDE DETECTORS • Next to a door or window that would be affected by drafts i.e. extractor fan or Ceiling Mounted - position at least 12" from any wall. air vent Wall Mounted - position at least 6" from ceiling, but not lower than a light switch. •... -
Page 9: Tamper Protection
Alignment marks Figure 15 - Detector fully aligned and installed on mounting base Figure 13 - Installing the base 8. TAMPER PROTECTION Alignment The Wireless Combination Smoke, Heat and Carbon Monoxide Detector has a built- marks in tamper switch which will cause a tamper signal to be transmitted to the control panel if the detector is removed from the mounting base. -
Page 10: Sensitivity Check
9.1 SENSITIVITY CHECK Anti-Tamper Anti-Tamper Examine the detector and observe the LED, if the LED is blinking GREEN once every Locking Tab Locking Tab 12 seconds the detector is operating normally and sensitivity is within the marked Removed sensitivity range on the back of the detector. If the LED is blinking YELLOW every 8 seconds and beeping every 48 seconds it may no longer be within the marked sensitivity range and should be cleaned. -
Page 11: Maintenance
9.6 CO ALARM FUNCTIONAL TEST • NFPA 72 states: Fire-warning equipment for residential occupancies are After pressing and holding the CO test button for 12 seconds as in the previous capable of protecting about half of the occupants in potentially fatal fires. step, the detector will enter a CO GO/NO-GO test mode and the LED will blink Victims are often intimate with the fire, too old or too young, or physically or GREEN and BLUE for 2 minutes. -
Page 12: If The Alarm Sounds
detect with the human senses. Under normal conditions in a room where fuel • Make a home escape plan. Draw a map of your home showing all doors and windows. Discuss the plan with everyone in your home. burning appliances are well maintained and correctly ventilated, the amount of carbon monoxide released into the room by appliances should not be dangerous. -
Page 13: Detector Replacement
manufacture. WARNING: IMPORTANT INFORMATION FOR THE USER NOTE: When the detector is removed from its base, a tamper message is sent to the Individuals with medical problems may consider using warning devices which central station. provide audible and visual signals for carbon monoxide concentrations under 30 The detector will also cause a trouble condition once it has reached the end of its ppm. - Page 14 • Consult the dealer or an experienced radio/television technician for help 14.1 MODEL 51000-600 “For your information, The National Fire Alarm Code, NFPA 72, reads as follows: Control Unit: Vivint CP04 (VS-SH2000-000) Doc 77-600022-001 – Rev A.2 “11.5.1 Required Detection.”...
Need help?
Do you have a question about the 51000-600 and is the answer not in the manual?
Questions and answers
I’m attempting to change batteries. Every time I insert the new ones it activates the alarm.
To change the batteries in an Apollo 51000-600 without activating the alarm:
1. Remove the detector from the mounting base.
2. Remove the batteries. A flat-bladed screwdriver may be used carefully to avoid damaging the batteries.
3. Wait at least 20 seconds for the detector to fully power down.
4. Install 2 new Panasonic CR123A or Energizer EL123AP batteries, following the polarity markings on the detector.
