StarTech.com CDP2HVGUASPD Quick Start Manual page 2

Presentation Mode Switch
Slide the Presentation Mode Switch from off to on to prevent the connected Host
•
Computer from going into sleep mode or placing a connected Display Device into
standby mode.
Inserting/Removing MicroSD Card
Inserting
Insert an MicroSD Card, label side up, into the MicroSD Card Slot on the Docking
1.
Station.
Once inserted, push the MicroSD Card into the MicroSD Card Slot until it clicks into
2.
place.
Note: The Host Computer's Operating System (OS) will automatically detect the
MicroSD Card and install the required driver software.
Access the data stored on the MicroSD Card inserted in step 1.
3.
Note: The MicroSD Cards may require formatting before they appear up on the Host
Computer.
Removing
Warning: Removal of an MicroSD Card before it is safe could result in the loss or
corruption of data on the MicroSD Card.
Windows
Click on the Up arrow on the right side of the Taskbar.
1.
The System Tray will pop up, revealing a set of icons.
2.
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and receiver.
•
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•
Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation. Changes or modifications not expressly approved by StarTech.com could void
the user's authority to operate the equipment.
Industry Canada Statement
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.
CAN ICES-3 (B)/NMB-3(B)
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:
(1) This device may not cause interference, and (2) This device must accept any interference, including interference that may
cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation
est autorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d'en compromettre le fonctionnement.
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-
party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only
and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which
this manual applies by the third-party company in question. StarTech.com hereby acknowledges that all trademarks, registered
trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the
property of their respective holders.
Click on the Safely Remove Hardware icon.
3.
The Safely Remove Hardware screen will appear.
4.
Select the MicroSD Card, a message will appear telling you when it is safe to
5.
remove the MicroSD Card from the MicroSD Card Slot on the Docking Station.
macOS
On the Desktop, click and drag the USB Storage icon to the Trash Can icon. The
•
Trash Can icon will turn into an Eject icon indicating that it is safe to remove the
MicroSD Card from the MicroSD Card Slot on the Docking Station.
Physically Removing the MicroSD Card
Push the MicroSD Card into the MicroSD Card Slot on the Docking Station until
1.
the MicroSD Card clicks. The MicroSD Card will be ejected from the MicroSD Card
Slot.
Pull the MicroSD Card out of the MicroSD Card Slot.
2.
Driver Installation
The drivers should install automatically, however, if they do not, you will need to
manually install the driver.
Download the drivers from www.startech.com/CDP2HVGUASPD. Click on the
1.
Support tab, under Drivers, select the appropriate driver package for the Operating
System running on the Host Computer.
Once you have download and unzipped the driver. Click on the Installation Guide
2.
PDF and follow the instructions.
Warranty Information
This product is backed by a three-year warranty.
For further information on product warranty terms and conditions, please refer to www.startech.com/warranty.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents)
for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of
business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.
Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations
or exclusions contained in this statement may not apply to you.
Safety Measures
•
If product has an exposed circuit board, do not touch the product under power.
Mesures de sécurité
•
Si l'un des circuits imprimés du produit est visible, ne pas touchez le produit lorsqu'il est sous tension.
安全対策
製品に露出した状態の回路基盤が含まれる場合、電源が入っている状態で製品に触らないでください。
•
Misure di sicurezza
•
Se il prodotto ha un circuito stampato visibile, non toccare il prodotto quando è acceso.
Säkerhetsåtgärder
•
Rör aldrig vid enheter med oskyddade kretskort när strömmen är påslagen.
