INSIDE FRONT COVER
EN
Included in this shipment:
• 84" Microsoft Surface Hub loaded with Windows OS
• Welcome Kit
• 6mm hex wrench
• Power cable
• Wireless keyboard (with two AAA alkaline batteries and a wireless keyboard receiver)
• Two wireless pens
• Screen cleaning cloth
You'll need to accept the enclosed License Agreement and Warranty before use.
Not packaged for retail sale.
More information is available at https://www.microsoft.com/surface/support/surface-hub.
This symbol identifies safety and health messages in this guide.
WARNING: Do not attempt repairs
Do not attempt to take apart, open, service, or modify the product or its accessories. Doing so could present the risk of electric shock or other
hazard. Heed all warnings and follow all instructions.
WARNING: Handling and site prep
The 84" Microsoft Surface Hub weighs approximately 280 pounds (127 kg.), and is (46 x 86.9 x 4.1 inches or 116.8 x 220.6 x 10.4 cm). To reduce the
risk of injury due to this size and weight:
• Use the Site Readiness Guide to make sure the Surface Hub and its shipping container will fit into the elevators, hallways, doorways, etc on the
way to the place it will be unpacked and mounted. You can find a copy of the Site Readiness Guide at
http://www.microsoft.com/surface/support/surface-hub.
• Always have at least four people for unpacking and installation.
• Prepare the mounting system before unpacking the Surface Hub.
• Once Surface Hub is unpacked, it will need to be mounted immediately. If you're mounting Surface Hub onto a rolling stand, lock or block the
wheels of the stand before unpacking.
• Always have two people securing Surface Hub upright throughout the unpacking process.
• Keep the assembly area clear of packing materials, and remove materials after each step.

Before you begin

Keep the 84" Surface Hub upright at all times.
•
The shipping crate is on wheels. Be sure to work on a level surface to ensure the shipping crate does not roll while
•
unpacking.
Unpack the 84" Surface Hub in the same room where it will be mounted.
•
Allow Surface Hub to come to room temperature for at least 6 hours before unpacking when moving the package in
•
from a cold environment.
Prepare the mounting system before unpacking the 84" Surface Hub.
•

Tools required

Use care with all tools while you're unpacking the 84" Surface Hub to avoid cutting or damaging its screen. You'll need:
• Scissors for cutting away the silver anti-static packing bag and for cutting the packing straps
• A 6mm hex wrench for detaching the shipping brackets (included)
Unpack Surface Hub 84"
As you unpack the Surface Hub, keep the area clear by removing packing materials at the end of each step.
1. Place the shipping crate so that the back faces the mounting system.
Note: The Microsoft Surface Hub logo is on the front of the box.
2. Cut the plastic packing straps.
.
