Reference Guide for End Users of the Microsoft Surface Hub

Ways of using the Surface Hub

1. Project the contents of your laptop:
o Windows 10 systems are wireless and wired capable.
o Windows 7 has wired capability only (must have HDMI or DisplayPort connection)
2. Whiteboard
3. As a standalone computer
4. For Skype meetings
5. To access documents from your OneDrive

System Components

Wake / Sleep

-
Wakes up based on motion detection.
-
Goes to sleep when it stops detecting motion
-
If the device does not turn on automatically, go through these steps until it wakes up:
•
Make sure that it is turned on (power button on the right panel must be green)
•
Swipe up from the bottom of the screen. If a menu appears, select Exit Full Screen
On the side kay pad, press the Source button
•
PLEASE MAKE SURE THAT BEFORE YOU LEAVE THE ROOM YOU CLICK ON "END
SESSION" AT THE BOTTOM OF THE SCREEN
to toggle through the possible video input sources
February 2018
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Surface Hub and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Microsoft Surface Hub

Summary of Contents for Microsoft Surface Hub

  • Page 1: System Components

    Reference Guide for End Users of the Microsoft Surface Hub Ways of using the Surface Hub 1. Project the contents of your laptop: o Windows 10 systems are wireless and wired capable. o Windows 7 has wired capability only (must have HDMI or DisplayPort connection) 2.
  • Page 2 Center in the lower right corner of your screen. Click on the Connect button. (You may need to click expand first) You can now select the id of the Surface Hub and your laptop will automatically display its screen on the Surface Hub.
  • Page 3 Reference Guide for End Users of the Microsoft Surface Hub Using the Surface Hub as a Whiteboard On the Surface Hub, click on Whiteboard or simply remove a pen from the docking station. Use the pens or your finger to draw.
  • Page 4 Tap on the People Icon to search for a user to add to the call. This only applies to contacting County Employees. Users can also call the Surface Hub on Skype, by searching for its name (e.g. CEORESOURCEMANZANITA@ceo.sccgov.org February 2018 Page 4...
  • Page 5 You can only call County Employees. Using the Surface Hub as a Computer There are many apps that are supported on the Surface Hub that may be utilized. To access all the supported apps, simply tap or click on the Windows Icon at the bottom of the screen.
  • Page 6 When you end a session, all of the files you were working on, anything on the whiteboard, and other meeting info will be completely cleared from the Surface Hub to get it ready for the next session. If you want to save your work, you have two options: You can save the file to OneDrive, log-in if you are not already logged in to save the file or email the files to yourself and/or other attendees from the hub.
