Chronograph Isa 8161/202, 8171/201 - Diesel DZ1067 User Manual

Chronograph ISA 8161/202
(1 crown/2 pushers)
SETTING THE TIME
1. Pull crown out to position 3.
2. Set time by turning the crown.
3. Push the crown back to position 1.
SETTING THE DATE
1. Pull crown out to position 2.
2. Set date by turning the crown.
3. Push the crown back to position 1.
RESETTING CHRONOGRAPH (after battery exchange or mishandling only)
1. Press both A and B pushers at the same time.
2. Next press B to reset the minutes.
3. Then press A to reset seconds.
4. To exit press both A and B pushers at the same time.
MEASURING CUMULATIVE TIMES
1. Press A pusher to start.
2. Press A pusher to stop.
3. Press B pusher to reset.
MEASURING SPLIT TIMES
1. Press A pusher to start.
2. Press B pusher to split.
3. Press B pusher to restart.
4. Press A pusher to stop.
5. Press B pusher to reset.
Chronograph ISA 8171/201
TIME AND DATE SETTING
1. Pull crown out to position 2.
2. Rotate crown clockwise until the previous day's date is shown in the date window.
3. Pull crown out to position 3.
4. Rotate crown clockwise until the correct date is shown in the date window.
5. Continue to rotate crown to set correct am/pm time.
6. Return crown to position 1.
NOTE: Do not set the date between 9:00 p.m. and 12:30 a.m. to ensure accuracy.
CHRONOGRAPH OPERATION
1. Press A to start/stop the chronograph.
2. Press B to restart/reset.
NOTE: After 2 hours of continuous running, the chronograph will automatically stop and reset to save the battery.
SPLIT TIME
1. Press B while the chronograph is running.
2. Press B again to return to the chronograph.
3. Press A to finalize timing.
4. Press B to reset.
CHRONOGRAPH ZERO RESET
1. If either of the chronograph hands is not at the zero (12:00) position, pull crown out to position 2.
2. Press B to reset chronograph minute hand. Each press of B will advance the chronograph minute hand by one increment or
press and hold B for fast advance.
3. Press A to reset chronograph 1/5 second hand. Each press of B will advance the chronograph 1/5 second hand by one
increment or press and hold B for fast advance.
MINUTE HAND
(A)
SECOND HAND
(1) (2) (3)
(B)
DATE
CHRONOGRAPH
(A)
1/5 SECOND HAND
CHRONOGRAPH
MINUTE HAND
(1) (2) (3)
DATE
(B)
SECOND HAND
