Zodiac Jandy Pro Series Installation And Operation Manual
Slide valve and backwash valve
Hide thumbs
Also See for Jandy Pro Series:
- Installation and operation manual (32 pages) ,
- Installation and operation manual (12 pages)
Advertisement
Quick Links
FOR YOUR sAFETY - This product must be installed and serviced by a contractor who is licensed and
qualified in pool equipment by the jurisdiction in which the product will be installed where such state or
local requirements exist. The maintainer must be a professional with sufficient experience in pool equipment
installation and maintenance so that all of the instructions in this manual can be followed exactly. Before
installing this product, read and follow all warning notices and instructions that accompany this product.
Failure to follow warning notices and instructions may result in property damage, personal injury, or death.
improper installation and/or operation will void the warranty.
improper installation and/or operation can create unwanted electrical hazard which can
cause serious injury, property damage, or death.
ATTEnTiOn insTAllER - This manual contains important information about the installation,
operation and safe use of this product. This information should be given to the owner/
operator of this equipment.
slide Valve and Backwash Valve
WARning
insTAllATiOn And
OPERATiOn MAnUAl
Jandy Pro series
English
Advertisement
Related Manuals for Zodiac Jandy Pro Series
Summary of Contents for Zodiac Jandy Pro Series
- Page 1 And OPERATiOn MAnUAl English Jandy Pro series slide Valve and Backwash Valve WARning FOR YOUR sAFETY - This product must be installed and serviced by a contractor who is licensed and qualified in pool equipment by the jurisdiction in which the product will be installed where such state or local requirements exist.
-
Page 2: Table Of Contents
Page 2 English Jandy Pro Series, Slide Valve & Backwash Valve Installation & Operation Manual ® Table of Contents section 1. safety information ......................... 3 section 2. sVlV8 installation ......................... 4 section 3. sVlV2 and Versa-Coupler installation ................. 5 section 4. normal Operation ........................6 section 5. -
Page 3: Section 1. Safety Information
• Water temperature for test must NOT EXCEED 100°F (38°C). • Limit test to 24 hours. After test, visually check system to be sure it is ready for operation. notice: These parameters apply to Jandy Pro Series equipment only. For non-Jandy equipment, consult equipment manufacturer. -
Page 4: Section 2. Svlv8 Installation
WARning The Jandy Pro Series Pro Series Slide Valve is designed to be used on either sand or diatomaceous earth (DE) filters Ensure that all electrical power to the system is turned... -
Page 5: Section 3. Svlv2 And Versa-Coupler Installation
To Filter Body (cut away view) To Pool nOTE For new installations other than Jandy Pro Series (PORT A) DEL48 or DEL60, use the SVLV2 and the Versa Coupler Kit, p/n 8044. See Figure 4. Filter Outlet If using the Slide Valve with a Pentair®... -
Page 6: Section 4. Normal Operation
Wait for all the air to evacuate the system. From Pump (PORT B) (Jandy Pro Series DEL, DEV, and JS series Filters) Ensure that the Slide Valve handle is fully Filter Inlet depressed (handle and piston pushed all the way (PORT D) down). -
Page 7: Section 6. Servicing
Page 7 Jandy Pro Series, Slide Valve & Backwash Valve Installation & Operation Manual English ® section 6. servicing (Other Manufacturers Filters with the filter top port as the inlet) Ensure that the Slide Valve handle is fully depressed (handle and piston WARning pushed all the way down). -
Page 8: Section 7. Winterizing
Page 8 English Jandy Pro Series, Slide Valve & Backwash Valve Installation & Operation Manual ® section 7. Winterizing CAUTiOn shaft Assembly If not properly winterized, damage to the Slide Valve lid Union will occur, which will increase the potential of injury. Turn off the system pump(s). - Page 9 Page 9 Jandy Pro Series, Slide Valve & Backwash Valve Installation & Operation Manual English ® 11.5 Flow Rate, GPM Figure 10. slide Valve head loss Curve (slide Valve with dE Filter data shown)
-
Page 10: Section 8. Slide Valve Exploded View And Replacement Parts List
Page 10 English Jandy Pro Series, Slide Valve & Backwash Valve Installation & Operation Manual ® section 8. slide Valve Exploded View and Replacement Parts list Order description Qty. Model Part no. Rebuild Kit (O-rings, Roll Pins and SVLV8 R0442100 Index Plate/Lid) SVLV2 O-ring, Lid... - Page 11 Page 11 Jandy Pro Series, Slide Valve & Backwash Valve Installation & Operation Manual English ® 3, 4 1, 2, 3, 4 3, 4 1, 2, 3 1, 2, 3, 4 1, 2, 3 1, 2, 3, 4 1, 2...
- Page 12 2620 Commerce Way, Vista, CA 92081 1.800.822.7933 | www.ZodiacPoolSystems.com ZODIAC is a registered trademark of Zodiac International, S.A.S.U., used under license. ® All trademarks referenced herein are the property of their respective owners. ©2012 Zodiac Pool Systems, Inc. H0569400 Rev F 1206...
