- Page 1 WF150K Whole House Central Water Filter INSTALLATION INSTRUCTIONS & OPERATING MANUAL Ver. 02/2020 Copyright ©2005-2020 ISPRING WATER SYSTEMS, LLC. All rights reserved.
- Page 3 From various residential water filtration systems that purify your water in everyday life, to drinking water faucets that deliver pure, healthy, and tasty water to you and your family. At iSpring, we strive for high standard products and aim to make excellent drinking water accessible for all households.
-
Page 5: Table Of Contents
Installation Instructions ....................11 Using the System Programming the Central Water Filtration System ............ 14 Operation of WF150K Central Whole House Filtration System ........ 17 Care of Your Central Water Filtration System ............20 Troubleshooting ......................21 Warranty Warranty and Registration ..................23 www.123filter.com... -
Page 6: User Information
● The unit should be placed only on flat surfaces. Do not mount on a wall. ● This product is designed for residential use only. Contact iSpring customer service to inquire about using in non-residential settings. -
Page 7: Dimensions
Dimensions TOP VIEW SIDE VIEW FRONT VIEW • Note:all dimensions are in millimeters unless otherwise specified. www.123filter.com | (678) 261-7611 | support@123filter.com Page 4... -
Page 8: Product Operation & Specifications
Product Operation & Specifications Though testing was performed under standard laboratory conditions, the actual performance of the system may vary based on local water conditions and quality. SPECIFICATIONS Model WF150K Hydrostatic Test Pressure 350 psi (24.15 bar) 20 ~ 125 psi Working Pressure Limits (minimum/maximum) (1.38 ~ 8.62 bar) -
Page 9: Before You Start
Before You Start Warning This system can only be used with 120V/60Hz unidirectional AC power. Do not place anything over the power cord and set the unit where the power cord will not be stepped on or tripped over. Electric shock hazard: Do not overload sockets or extension cords. -
Page 10: Material Details
Material Details 1. Inspect Shipment: One machine and its accessories are included: ① power adapter (white box, 1 pcs.) (adhered to the base), ② sewage pipe (translucent pipe, 1 pcs.), ③ stainless steel braided hose (NPT6M connector, 2 pcs.), ④ stainless steel clamps (in the PE bag, 1 pcs.), ⑤ hex key (in the PE bag, 1 pcs.). 2. - Page 11 5. Bypass Assembly www.123filter.com | (678) 261-7611 | support@123filter.com Page 8...
-
Page 12: Installation Requirements
Installation Requirements (1) Equipment Installation Conditions The installation location should be well-ventilated and protected against wind and rain. Avoid direct sunlight and radiation from any heat sources. The relative humidity of the installation and use environment should not exceed 75% RH. ... - Page 13 If the water inlet pressure is higher than 125 psi, a pressure reducing valve must be installed at the water inlet pipe of the water purifier. If the water inlet pressure is lower than 20 psi, a booster pump must be installed at the water inlet pipe of the water purifier to ensure the working pressure meets technical requirements.
-
Page 14: Installation Instructions
Installation Instructions (1) General Bypass Installation i. Hold the knob or use a bypass tool to rotate the knobs. ii. Water supply will be bypassed when the knobs are horizontal. iii. The bypass is in service status when knobs are oriented vertically. iv. - Page 15 (4) Equipment Installation Step 1. Confirm proper installation conditions, then unpack the equipment and verify that all accessories are present. Prepare the installation tools and confirm that the water inlet and outlet pipes, power supplies, sewage pipes, and floor drains at the installation site meet the appropriate requirements.
- Page 16 Step 9. Open a cold water tap nearby and let the water run a few minutes till the water runs clean or until the system is free of foreign material caused by plumbing work. Step 10. Then, slowly open the water inlet valve (the valve should be opened at an angle of about 45°), fully open the water outlet valve.
-
Page 17: Programming The Central Water Filtration System
Programming the Central Water Filtration System (1) Button Configuration Key Pad Configuration • MENU This function is used to enter the basic setup information required at the time of installation. • SET/REGEN This function is used to initiate an immediate or delayed manual regeneration. •... - Page 18 (c) "↑" / "↓" When the display is in a menu option, these keys can be used to adjust the value or option. (2) Notes (a) Combination key Press and hold "↑" and "↓" at the same time for 3 seconds in the unlocked state to regeneration cycle setting (backwash, rinse, lock/unlock value).
- Page 19 (4) Press and hold "MENU" and "SET/REGEN" at the same time for 3 seconds to enter the following user menu settings: SYSTEM LANGUAGE: Choose the system language. UNITS: Choose the system unit of measurement: metric or gallons. SMART CLEAN: When set to ON, the system will perform a 10 (adjustable) minute backwash and rinse if there is no water flow detected after 7 (adjustable) days.
-
Page 20: Operation Of Wf150K Central Whole House Filtration System
Operation of WF150K Central Whole House Filtration System (1) Product Functions and Features The central whole house water filtration system utilizes high-quality KDF85 and coconut shell activated carbon to further purify municipal tap water, effectively reducing odor, residual chlorine, and organic content. - Page 21 (d) Water Purification Process: Tap WaterActivated CarbonAlloy Filter MediaPurified Water (2) Structure Automatic multi-way electronic control valve Made with high strength polyphenylene ether (PPE) with glass fiber, making the product hygienic, reliable and durable Corrosion resistance Structural strength, well-designed Filter ...
- Page 22 Main Functions Daily Reserve Backwash Override/Rinse Override Forced Regeneration Smart Cleaning Display Format: Metric format and US format are available to meet the different customers' requirements. Multi-Language Function: English, Spanish, French and other languages are available. ...
-
Page 23: Care Of Your Central Water Filtration System
Care of Your Central Water Filtration System The product can be used frequently after installation and commissioning have been completed. With an uninterrupted power supply, the user does not need to perform other operations on the machine. If the equipment fails or experiences other exceptional circumstances, the inlet and outlet valves ... -
Page 24: Troubleshooting
Troubleshooting ISSUE POSSIBLE CAUSE POSSIBLE SOLUTION Unit fails to initiate a No power supply Check electrical service, fuse, regeneration cycle etc. Reset time. Power failure Iron or scale builds up in line Low water pressure Clean pipes or add WDS series feeding unit or ED2000 before the system. - Page 25 Need help with troubleshooting? If you have any questions or find there are missing parts or damage, please call 1-678-261-7611 or visit www.ispringfilter.com When calling, please be prepared to provide the model of your product. (The model of this product is "WF150K".) www.123filter.com | (678) 261-7611 | support@123filter.com...
-
Page 26: Warranty And Registration
Warranty Registration To register your product for the warranty, visit our website at 123filter.com and go to the “Warranty” tab. We provide a 30-day money back guarantee, a 1-year manufacturer warranty, and lifetime tech support for all of our products. However, we do not have the order information from websites other than 123Filter.com (Amazon, Home Depot, etc.), so please be sure to fill in that information upon registration of your system. - Page 28 Atlanta, GA USA iSpringFilter.com For questions, comments, or technical support, please contact us at: support@123Filter.com (678) 261-7611 Monday-Friday 8:30 a.m. - 5:30 p.m. EST...
