Flowserve Valtek Installation, Operation & Maintenance Instructions Manual page 5

Monitoring Port
(optional)
Bellows Seal Housing
(Item No. 5)
Bonnet Flange Bolting
(Item No. 108,114)
Lower Stem Guide
(Item No. 82, 83)
Stem Guide Housing
(Item No. 31)
Seat Ring
(Item No. 20)
Seat Ring Gasket
(Item No. 55)
Body
(Item No. 1)
Figure 2: Guardian II Metal Bellows Seal with Integral Flange Design
Note: Item numbers correspond directly to the valve's bill of material. Refer to bill of material for specific numbers.
O
S
Actuator / Yoke Assembly
Upper Guide
(Item No. 86, 87)
Packing
(Item No. 88)
Packing Spacer
(Item No. 93 - 99)
Tell-tale Tap
Shrouded Bellows Assembly
(Item No. 6)
Bellows Assembly to
Housing Gasket
(Item No. 58)
Tack Weld
Bellows Plug Head
(Item No. 50)
12-5
