(Refer to Step 8 in
"Reassembly" Section)
Spring Guide Retainer
should compres
approximately 1/ 8-inch
Plug Stem
Jam Nut
Stroke + 1/ 16-inch
1-inch to less stroke
stroke +1/ 32-inch
(See Table II)
12-10
Figure 5: Plug Thread Adjustment
Anti-rotation Pin
Bellows Seal Assembly
Bellows Seal Plug
