INSTRUCTION MANUAL
Metal Shear
JS1602
DOUBLE INSULATION
Read before use.

Advertisement

Table of Contents
loading

Related Manuals for Makita JS1602

Summary of Contents for Makita JS1602

  • Page 1 INSTRUCTION MANUAL Metal Shear JS1602 DOUBLE INSULATION Read before use.

  • Page 2: Specifications

    SPECIFICATIONS Model JS1602 Max. cutting capacities Steel up to 400 N/mm 1.6 mm (16 ga) Steel up to 600 N/mm 1.2 mm (18 ga) Steel up to 800 N/mm 0.8 mm (22 ga) Aluminum up to 200 N/mm 2.5 mm (13 ga) Min.

  • Page 3: Ec Declaration Of Conformity

    If operating a power tool in a damp location WARNING: The vibration emission during actual is unavoidable, use a residual current device use of the power tool can differ from the declared val- (RCD) protected supply. Use of an RCD reduces ue(s) depending on the ways in which the tool is used the risk of electric shock.
  • Page 4 Service Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. Follow instruction for lubricating and chang- ing accessories. SHEAR SAFETY WARNINGS Hold the tool firmly. Secure the workpiece firmly.

  • Page 5: Functional Description

    The thickness of materials to be sheared depends upon FUNCTIONAL DESCRIPTION the type (strength) of the material. The maximum shear- ing thickness is indicated in the table below in terms of various materials. Attempting to shear materials thicker CAUTION: than indicated will result in tool breakdown and/or possi- •...

  • Page 6: Operation

    Remove the blade securing bolts with the hex wrench After securing the upper blade, be sure that there is no provided and then rotate or replace the blades. gap left between the upper blade and the beveled sur- face of the blade holder. ► 1 .

  • Page 7: Optional Accessories

    The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose. If you need any assistance for more details regard- ing these accessories, ask your local Makita Service Center. • Shear blades Always hold the tool firmly with one hand on housing.
  • Page 8 Makita Europe N.V. Jan-Baptist Vinkstraat 2, 3070 Kortenberg, Belgium Makita Corporation 3-11-8, Sumiyoshi-cho, Anjo, Aichi 446-8502 Japan 885145A229 www.makita.com 20190131...
