Model Identification; Serial Number Date Code; Air Flow, Weights And Filter Sizes - Airxcel CEA1012A Installation & Operation Manual

1.2

Model Identification

The model identification number is found on the data sticker. Rating plate located on side panel.
Example C G A 1
Position 1 2 3 4
1 Unit Designation/Family
2 Energy Efficiency Ratio (EER)
3 Refrigerant Type
4 Compressor Type/Quantity
5
Unit Capacity/Nominal
6
Cooling (BTUH)
7
8 System Type
Power Supply
9
(Volts-Phase-Hz)
10
Heat Designation
11
@ Rated Voltage
KW = Kilowatt
12
Ventilation
13
Configuration
14 Dehumidification
15 Controls
16 Operating Condition
Note: Not all options are available with all configurations. Contact your ICE sales representative for configuration details and
feature compatibility.
1.3

Serial Number Date Code

20 = 2020 01 = January
21 = 2021 02 = February
22 = 2022 03= March
23 = 2023 04 = April
1.4

Air Flow, Weights and Filter Sizes

Complete electrical and performance specifications and dimensional drawings are in the ICE CEA/
CGA Product Data Sheets.
ICE CEA/CGA1012–1060 Wall Mount AC I&O Manual
03/2021 Rev.1
0 3 6 A A 0 5
5 6 7 8 9 10 11
C = Industrial Climate Engineering (ICE)
E = Standard Efficiency
G = High Efficiency
A = R-410a
1 = Single
012 = 12,000 036 = 36,000
020 = 20,000 042 = 42,000
024 = 24,000 048 = 48,000
030 = 30,000 060 = 60,000
A = Air Conditioner
A = 208/230-1-60 D = 460-3-60
=
Z
C = 208/230-3-60
575V,3ø,60Hz
000 = No Heat 080 = 8KW
022 = 2.2KW 090 = 9KW
036 = 3.6KW 100 = 10KW
040 = 4KW 120 = 12KW
050 = 5KW 150 = 15KW
060 = 6KW
A = Solid Front Door
C = Economizer
D = Motorized Damper w/Pressure Relief
E = Motorized Damper w/Pressure
Relief & Independent Motorized
Damper Control
F = No Free Cooling, 100% Emergency
Ventilation Only w/Independent Control
R = Electric Reheat
T = Electric Reheat w/Humidity Control
+ = None
A = Power Fail Alarm w/Additional Lockouts
C = 24V EMS Relay Kit
D = 24V EMS Relay Kit
w/Factory Installed T-Stat
E = Factory Installed T-Stat
+ = None
A = Evaporator Freeze Sensor (EFS)
C = EFS w/Hot Gas Bypass
M = Extreme Duty w/Hard Start & EFS
N = Hard Start
P = Hard Start w/Low Ambient & CCH
Q = Hard Start w/Low Ambient &
Fan Cycle Control (FCC)
R = Crank Case Heater (CCH)
T = Hard Start w/EFS
U = Hard Start w/Hot Gas Bypass
V = Hard Start w/Low Ambient &
CCH & EFS
W = Low Ambient w/CCH
X = Hot Gas Bypass
Y = Low Ambient w/CCH & FCC
Z = Low Ambient w/CCH & EFS
1 = Low Ambient w/FCC
2 = Low Ambient w/FCC & EFS
3 = CCH w/Hot Gas Bypass
+ = None
05 = May
06 = June
07 = July
08 = August
0 C R + + + 1
12 13 14 15 16 17 18
Indoor Air Quality
17
Features
18 Air Flow
Compressor
19
Location
20
Filter Option
Corrosion
21
Protection
22
Engineering
Revision Level
23
24 Cabinet Color
25 Sound Attenuation
26 Security Option
27 Packaging
Fastener/Drain Pan
28
Option
29 Unused
30 Special Variation
09 = September
10= October
11 = November
12 = December
6
D A + A 1 1 +
19 20 21 22 23 24 25
D = Dry Bulb Sensor
E = Dry Bulb Sensor w/Dirty Filter
G = Dirty Filter Sensor
+ = None
1 = Top Supply/Bottom Return
D = Left Hand
E = Right Hand
A = 2" Pleated (MERV 8, AC/HP-C)
C = 2" Charcoal
D = MERV 11 High Filtration Package
E = MERV 13 High Filtration Package
F = Filter Access Through Return Air Grille
W = Aluminum Washable
+ = None
A = Condenser Coil Only
C = Evaporator Coil Only
D = Both Coils Condenser & Evaporator
E = All Coils Cond/Evap/Reheat
F = Coat All
K = Coastal Package
+ = None
$ = Special
A1
1 = Beige
2 = Gray
3 = Carlsbad Canyon
4 = White
5 = Stainless Steel Exterior
6 = Dark Bronze
7 = .050 Aluminum Stucco
8 = Mesa Tan
9 = Pebble Gray
A = Stainless Steel - Unit
$ = Custom Color (Powder Coat)
2 = Compressor Blanket
+ = None
A = Lockable Access Plate/Tamper Proof
+ = None
1 = Crating
2 = Coil Covering
3 = ISPM 15 Compliant
+ = None
A = Stainless Steel Fasteners
C = Stainless Steel Drain Pan
D = Stainless Steel Fasteners & Drain Pan
+ = None
+ = None
$ = Special
+ = None
$ = Special Configuration Not Covered by
Model Nomenclature
+
+ + + +
26 27 28 29 30
