  • Page 1 OWNER’S MANUAL TRINITY ECOSTORAGE™ 5-TIER 18"x18"x56.5" SQUARE RACK – CHROME Model # TBFZ-0956 Important / Important / Importante FOR QUICK & EASY 3D ASSEMBLY INSTRUCTIONS Direct ives int elligent es POUR DES DIRECTIVES D’ASSEMBLAGE 3D RAPIDES ET FACILES Inst rucciones Int eligent es PARA INSTRUCCIONES DE ENSAMBLAJE RÁPIDAS Y SENCILLAS EN 3D...

  • Page 2: Parts List

    Your TRINITY EcoStorage™ 5-Tier Square Rack should include the following parts. Please inspect box contents to ensure you have received all components. If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY Customer Service: 800.985.5506 or customerservice@trinityii.com. Parts can also be requested online at www.trinityii.com (Help &...
  • Page 3 (A) and make sure height is identical for each BOTTOM POLE (A). Do NOT place more than one pair on each pole at a time. Note: There will be a very small gap in-between two locked SLIP SLEEVES (G)—this is normal. © 2019 TRINITY - 800.985.5506...
  • Page 4 • Use a rubber mallet, if needed, to secure SHELF (D). STEP 4 In the same way as indicated in STEP 2 & 3, install BASKET (E). E (1) G (8) Note: • Use a rubber mallet, if needed, to secure BASKET (E). © 2019 TRINITY - 800.985.5506...
  • Page 5 • Shelves, Sidebar and baskets are adjustable in 1” increments and can be placed as needed to best fit storage needs. • Use a rubber mallet, if needed, to secure SHELVES (D), BASKET (E) and SIDEBAR W/ HOOKS (F). © 2019 TRINITY - 800.985.5506...
  • Page 6 With a 1/4” drill bit, drill a hole 1-1/4” deep at each marked location. Push Anchors flush into each hole. Place Shelving Rack into position. Insert Screw through Washer and backside frame of top shelf as shown. Fasten Screw tightly into Anchor. Do this on both Anchors that were placed in wall. © 2019 TRINITY - 800.985.5506...

  • Page 7: Service Parts List

    SERVICE PARTS LIST – TBFZ-0956 TRINITY Customer Service provides the following replacement parts: Part Number Description Part Number Description ZSV-03-080-1818 Shelf ZSV-99-008-3010 Locking Caster ZSV-02-007-0010 Sidebar w/ Hooks XXX-97-002-0001 Wrench ZSV-04-029-1675 Top Pole ZSV-21-013-1818 Basket ZSV-01-030-2523 Pole Connector XBK-01-011-2543 Slip Sleeve...

  • Page 8: Care And Maintenance

    9. Load the product evenly and place the heaviest items on the lower shelves. 10. Always lock the locking casters when not moving the product. CARE AND MAINTENANCE • Avoid harsh, abrasive cleaners, and other corrosive chemicals. • This product is not certified for outdoor use. © 2019 TRINITY - 800.985.5506...

  • Page 9: Product Registration

    PRODUCT REGISTRATION Thank you for purchasing a TRINITY EcoStorage™ 5-Tier Square Rack. In order to register your product and receive streamlined customer service, please fill out the following Product Registration Form and (1) fax the form to 310.347.4134 (2) complete the Product Registration Form online at www.trinityii.com or (3) scan and email the form to customerservice@trinityii.com.
  • Page 10 © 2019 TRINITY - 800.985.5506...

  • Page 11: Year Limited Warranty

    Product which shall not be greater than the amount of the purchase price of the Product, at the option of Trinity, during the warranty period. All replaced parts and Products become the property of Trinity and must be returned to Trinity.
  • Page 12 WE ARE HERE TO HELP! Please feel free to contact us. There are no questions too small, or any problems too big. We’re committed to providing our customers with the highest level of service. TRINITY Customer Service TEL: 800.985.5506 FAX: 310.347.4134 EMAIL: customerservice@trinityii.com Monday through Friday 5:00 AM –...
