- Page 1 OWNER’S MANUAL TRINITY PRO 4-TIER NSF CORNER WIRE SHELVING RACK Model # TBFZ-0927 / TBFPBA-0927...
-
Page 2: Parts List
PARTS LIST Your TRINITY Pro 4-Tier NSF Corner Wire Shelving Rack should include the following parts. Please inspect box contents to ensure you have received all components. If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY Customer Service: 800.985.5506 or customerservice@trinityii.com. - Page 3 SLIP SLEEVES (E). Stand the unit upright. Note: • The level side of SHELF (D) is the TOP side (the TRINITY logo on the corner cylinders should be right-side up). • Use a rubber mallet, if needed, to secure SHELVES (D).
- Page 4 Lower SHELF (D) over MIDDLE POLES (B) so that the corner cylinders of SHELF (D) are positioned over SLIP SLEEVES (E). Repeat Step 4 to install other SHELVES (D) as desired. Note: Use a rubber mallet, if needed, to secure SHELVES (D). © 2018 TRINITY - 800.985.5506...
- Page 5 Lower SHELF (D) over TOP POLES (C) so that the corner cylinders of SHELF (D) are positioned over SLIP SLEEVES (E). Repeat Step 6 to install other SHELVES (D) as desired. Note: Use a rubber mallet, if needed, to secure SHELVES (D). © 2018 TRINITY - 800.985.5506...
- Page 6 ASSEMBLY INSTRUCTIONS STEP 7 Feet Levelers are already screwed into BOTTOM POLES (A). Adjust as needed to ensure your shelving rack is level. © 2018 TRINITY - 800.985.5506...
- Page 7 SERVICE PARTS LIST – TBFZ-0927 TRINITY Customer Service provides the following replacement parts: Part Number Description Part Number Description XBK-01-011-2543 Slip Sleeve XBK-98-010-2535 Feet Leveler ZSV-04-006-2475 Top Pole ZSV-04-043-2700 Bottom Pole ZSV-01-013-2523 Pole Connector XBK-23-004-2517 End Cap ZSV-04-007-2000 Middle Pole...
- Page 8 SERVICE PARTS LIST – TBFPBA-0927 TRINITY Customer Service provides the following replacement parts: Part Number Description Part Number Description XBK-01-012-2543 Slip Sleeve XBK-98-010-2535 Feet Leveler PBA-04-006-2475 Top Pole PBA-04-043-2700 Bottom Pole ZSV-01-013-2523 Pole Connector XBK-23-004-2517 End Cap PBA-04-007-2000 Middle Pole...
-
Page 9: Care And Maintenance
800 lb (evenly distributed) Total weight capacity of Shelving Rack 3200 lb (evenly distributed) CARE AND MAINTENANCE • Avoid harsh, abrasive cleaners, and other corrosive chemicals • This item is not certified for outdoor use © 2018 TRINITY - 800.985.5506... -
Page 10: Product Registration
PRODUCT REGISTRATION Thank you for purchasing a TRINITY Pro 4-Tier NSF Corner Wire Shelving Rack. In order to register your product and receive streamlined customer service, please fill out the following Product Registration Form and (1) fax the form to 310.347.4134 (2) complete the Product Registration Form online at www.trinityii.com or (3) scan and email the form to customerservice@trinityii.com. -
Page 11: Year Limited Warranty
Product which shall not be greater than the amount of the purchase price of the Product, at the option of Trinity, during the warranty period. All replaced parts and Products become the property of Trinity and must be returned to Trinity. - Page 12 WE ARE HERE TO HELP! Please feel free to contact us. There are no questions too small, or any problems too big. We’re committed to providing our customers with the highest level of service. TRINITY Customer Service TEL: 800.985.5506 FAX: 310.347.4134 EMAIL: customerservice@trinityii.com Monday through Friday 5:00 AM –...
