- Page 1 ® Everything in its place. OWNER’S MANUAL TRINITY WOOD KITCHEN CART w/DRAWERS AND TRAY - WHITE Model # TBFLWH-1404...
-
Page 2: Parts List
Your TRINITY Wood Kitchen Cart w/Drawers and Tray should include the following parts. Please inspect box contents to ensure you have received all components. If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY Customer Service: 800.985.5506 or customerservice@trinityii.com. Parts can also be requested online via our “Contact Us”... - Page 3 (4) DOWELS (N). Then push down evenly until DRAWER FRAME (B) is pressed against WOOD TOP (A). Insert FRAME SCREW (L) through DRAWER FRAME (B) and fasten to WOOD TOP (A) using SCREWDRIVER (O). Make sure all SCREWS (L) are tightened. © 2017 TRINITY - 800.985.5506...
- Page 4 CASTER SIDEFRAME (D). Tighten CASTERS (H) D (1) H (2) P (1) with WRENCH (P). Use the provided caster wrench to tighten completely. Failure to do as instructed could result in the caster stem breaking. © 2017 TRINITY - 800.985.5506...
- Page 5 SHELVES (C) that face the HANDLE FRAME (E). Push SHELVES (C) and HANDLE FRAME (E) together. Place FRAME SCREWS (L) through holes in SHELVES (C) and tighten with SCREWDRIVER (O) to nuts in HANDLE FRAME (E). © 2017 TRINITY - 800.985.5506...
- Page 6 DRAWER (I) from the inside and tighten with SCREWDRIVER (O) to DRAWER PULL (J). Align rails on DRAWER (I) with rails on the Kitchen Cart. Push DRAWER (I) all the way into DRAWER FRAME (B). Repeat for the other DRAWER (I). © 2017 TRINITY - 800.985.5506...
-
Page 7: Usage Instructions
Kitchen Cart. Left-hand side Right-hand side Drawer Replacement Align rails on DRAWER (I) with rails on the Kitchen Cart. Push DRAWER (I) all the way into DRAWER FRAME (B). © 2017 TRINITY - 800.985.5506... - Page 8 SERVICE PARTS LIST – TBFLWH-1404 TRINITY Customer Service provides the following replacement parts: Part Number Description Part Number Description LNA-06-004-3018 Wood Top LWH-03-005-2516 Shelf LWH-07-002-1305 Drawer XXX-97-001-0002 Screwdriver ZSV-01-004-0420 Pull Screw XBK-98-002-2525 Foot Pad XBS-05-004-0275 Drawer Pull XXX-97-002-0001 Wrench XBS-05-004-1600...
-
Page 9: Care And Maintenance
Wood top can be cleaned with damp cloth and wiped dry immediately with dry cloth. If needed, solvent-based wood furniture cleaner can be used. • Clean up any spills immediately to prevent stains from forming on the wood top. • Do not let children climb or play on the cart. © 2017 TRINITY - 800.985.5506... -
Page 10: Product Registration
PRODUCT REGISTRATION Thank you for purchasing a TRINITY Wood Kitchen Cart w/Drawers and Tray. In order to register your product and receive streamlined customer service, please fill out the following Product Registration Form and (1) fax the form to 310.347.4134 (2) complete the Product Registration Form online at www.trinityii.com or (3) scan and email the form to... -
Page 11: Year Limited Warranty
Product which shall not be greater than the amount of the purchase price of the Product, at the option of Trinity, during the warranty period. All replaced parts and Products become the property of Trinity and must be returned to Trinity. - Page 12 WE ARE HERE TO HELP! Please feel free to contact us. There are no questions too small, or any problems too big. We’re committed to providing our customers with the highest level of service. TRINITY Customer Service TEL: 800.985.5506 FAX: 310.347.4134 EMAIL: customerservice@trinityii.com Monday through Friday 8:00 AM –...
