Vishay TSSP60 Series Manual

www.vishay.com
IR Sensor Module for Reflective Sensor, Light Barrier,
DESIGN SUPPORT TOOLS AVAILABLE
3 3
D D
3 D
3D Models
MECHANICAL DATA
Pinning
1 = GND, 2 = N.C., 3 = V , 4 = OUT
S
ORDERING CODE
Taping:
TSSP60..TT - top view taped
TSSP60..TR - side view taped
APPLICATIONS
• Reflective sensors for hand dryers, towel or soap
dispensers, water faucets, toilet flush
• Vending machine fall detection
• Security and pet gates
• Person or object vicinity activation
• Fast proximity sensors for toys, robotics, drones, and
other consumer and industrial uses
PARTS TABLE
38 kHz
Carrier frequency
56 kHz
Package
Pinning
Dimensions (mm)
Mounting
Application
Rev. 2.1, 10-Apr-2019
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
and Fast Proximity Applications
4
3
2
1
16797
Vishay Semiconductors
FEATURES
• Up to 2 m for presence and proximity sensing
• Uses modulated bursts of infrared light
• PIN diode and sensor IC in one package
• Low supply current
• Shielding against EMI
• Visible light is suppressed by IR filter
• Insensitive to supply voltage ripple and noise
• Supply voltage: 2.5 V to 5.5 V
• Material categorization:
compliance please see
DESCRIPTION
The TSSP60.. series are compact infrared detector modules
for presence and fast proximity sensing applications. They
provide an active low output in response to infrared
bursts at 940 nm. The frequency of the burst should
correspond to the carrier frequency shown in the parts table.
This component has not been qualified according to
automotive specifications.
TSSP6038
TSSP6056
Panhead
1 = GND, 2 = N.C., 3 = V , 4 = OUT
S
7.5 W x 5.3 H x 4.0 D
SMD
Presence sensors, fast proximity sensors
1
www.vishay.com/doc?91000
TSSP60..
for definitions of
www.vishay.com/doc?99912
Document Number: 82483
