Delfield SAF1S-S Specifications

Specification Line
Self-Contained Shallow Solid Door Reach-In Freezer
MODELS
 SSF1S-S_
1_section_stainless_interior_
_ full_door
 SSF1S-SH_ 1_section_stainless_interior_
_ half_door
 SAF1S-S_ 1_section_aluminum_interior_
_ full_door
 SAF1S-SH_ 1_section_aluminum_interior_
_ half_door
SSF2S-SH
SPECIFICATIONS
Exterior: Cabinet_exterior_sides,_front_and_shroud_
shall_be_22-gauge,_corrosion_resistant_stainless_steel.__
Upper_shroud_shall_be_hinged,_with_stay-open_feature_
to_provide_easy_access_to_refrigeration_system.
Interior:_Cabinet_interior_shall_be_22-gauge,_corrosion_
resistant_stainless_steel_(SS_models)_or_heavy_gauge_
aluminum_(SA_models).__Bottom_and_top_surfaces_are_
die_stamped_to_provide_radius_corners_and_recessed_
floor.__Three_chrome_plated_wire_shelves_are_provided_
per_section.__Shelves_rest_on_clips_which_are_adjustable_
in_1"_increments_on_stainless_steel_pilasters_affixed_to_
the_cabinet_interior.__Pilasters_are_removable_without_
tools_for_cleaning.__Interior_light_mounted_to_the_
interior_ceiling_is_controlled_automatically_through_
a_switch_mounted_in_the_hinge_assembly_to_protect_
against_breakage.__Door_openings_are_protected_with_
heavy_gauge_stainless_steel_breaker_strips.__An_air_duct_
 SSF2S-S_ 2_section_stainless_interior_
_ full_door
 SSF2S-SH_ 2_section_stainless_interior_
_ half_door
 SAF2S-S_ 2_section_aluminum_interior_
_ full_door
 SAF2S-SH_ 2_section_aluminum_interior_
_ half_door
STANDARD FEATURES
•_ Stainless_steel_interior_and_exterior_(SS)
•_ Stainless_steel_exterior,_aluminum_interior_(SA)
•_ Built_in_door_locks_with_heavy_duty_strikes
•_ Recessed_metal_door_handle
•_ Exterior_digital_thermometer_with_high/low_
temperature_alarm
•_ Easy_access_"flip_up"_shroud
•_ Three_chrome_plated_wire_shelves_per_section
•_ Tough_ABS_interior_door_liners
•_ 10'_attached_cord_and_plug_standard_on_115V_units
•_ 6"_adjustable_stainless_steel_legs
•_ Stainless_steel_breaker_strips
•_ Two_year_parts_&_labor_warranty
is_mounted_to_the_ceiling_assuring_low_velocity,_even_air_
movement_throughout_the_cabinet_interior.
Doors:_Exterior_shall_be_22-gauge,_corrosion_resistant_
stainless_steel.__Interior_liner_shall_be_resilient_high_impact_
ABS_material,_formed_to_protrude_beyond_the_door_gasket_
to_protect_the_gasket_from_tearing.__Each_door_has_two_
edge_mount,_self_closing,_cam_lift_style_hinges.__Doors_can_
be_removed_from_cabinet_without_the_use_of_tools.__Metal_
door_handle_is_recessed_into_the_door_for_easy_grip_without_
impacting_aisle_space.__Keyed_door_lock_is_mounted_in_the_
door_next_to_the_handle.__Lock_engages_into_a_heavy_duty_
strike_mounted_to_the_cabinet_face.__Door_gaskets_are_
magnetic_and_mount_to_the_door_snapping_in_place_and_are_
removable_without_tools.
Refrigeration system:__All_components_are_mounted_
to_the_exterior_cabinet_ceiling,_outside_the_food_zone_and_
are_assembled_as_one_piece_and_can_be_removed_as_one_
980_S._Isabella_Road Phone:_800-733-8948
Mt._Pleasant,_MI_48858 Fax:_800-669-0619
www.delfield.com Email:_info@delfield.com
Project_ __________________________
Item_____________________________
Quantity_ _________________________
CSI_Section_11400
 SSF3S-S_ 3_section_stainless_interior_
_ full_door
 SSF3S-SH_ 3_section_stainless_interior_
_ half_door
 SAF3S-S_ 3_section_aluminum_interior_
_ full_door
 SAF3S-SH_ 3_section_aluminum_interior_
_ half_door
OPTIONS AND ACCESSORIES
 Security_package
 6"_polyurethane_casters
 Door_field_rehingability
 Stainless_steel_interior_door_liner
 Additional_shelves
 Stainless_steel_back
 Laminate_on_front,_sides_and_back
 Bottom_mount_electrical
 Stainless_steel_banking_strip
 Heat_shield_end
 Stainless_steel_kick_plate
 4"_stainless_steel_utility_base
 220-60-1_electrical
 220-50-1_electrical
piece.__Environmentally_friendly_R404A_refrigerant_is_
used.__System_has_the_capability_of_maintaining_between_
-5˚F_and_0˚F_in_heavy_use_food_service_operations.__
Refrigerant_is_metered_using_a_highly_responsive_
thermostatic_expansion_valve.__Evaporator_defrost_is_
automatic_using_a_time_initiated,_time/temperature_
terminated_system_with_electric_heaters.__Evaporator_
condensate_is_eliminated_using_an_energy_efficient_hot_
gas_system.___
Electrical:_Standard_electrical_connections_shall_be_115V,_
60Hz,_single_phase.__A_10'_cord_and_plug_is_supplied_
attached_to_a_junction_box_mounted_on_the_exterior_top_
of_the_cabinet.__Three_section_unit_is_dual_voltage_and_
requires_hardwire_electrical_connection.
Approval__________________
Date_ _ ___________________
