OSD Menu_Exposure

LENS
1
Manual: Manual mode supports the fixed board lens or the manual iris lens.
Auto: AUTO mode sets the camera's iris automatically.
EXPOSURE
EXPO
1
LENS
2-MOTOR
2
BRIGHTNESS
SHUTTER
BACK-LIGHT
STARLIGHT
AGC
3D DNR
RETURN
2-motor
2
Enter the 2-Motor lens sub-menu. In this menu, you can adjust the following options:
AF mode
- ONESHOT: Select for auto focus.
- MANUAL: Select to manually adjust the camera's focus and zoom.
D&N filter
Select to synchronize the camera's auto focus when the camera changes between
day and night modes.
Initial
Start the camera's two motor lens.
2-MOTOR
AUTO
AF MODE
D&N FILTER
10
INITIAL
AUTO
RETURN
OFF
X4
10
HIGH
17
ONESHOT
SYNC OFF
ON
