Digital Watchdog Star-Light Plus DWC-D3563WTIR User Manual page 13

Installation - Instructions
Using the mounting template or your camera,
1
mark and drill the necessary holes to mount the
bracket to a wall or ceiling.
Pull a necessary wires through and make the
2
proper connections. See pages 14-15.
Use the two mounting screws to install the
3
camera on the wall or ceiling. See page 16 for
tilting and pan adjustment options.
Adjust the camera's zoom and focus as needed.
4
See page 16 for more information.
When the installation is completed, place the
5
camera's dome over the camera's body by
clicking the dome into place.
Detach the protection film from the dome to
6
complete the installation.
13
