Installation - Disassemble the camera
Before installing your camera, read the following cautions.
1. The mounting surface must withstand five times the camera weight.
2. Do not let the cables get caught in improper places or the electric line cover can
be damaged. This may cause a short or fire.
3. When installing your camera, do not allow any person to approach the installation
site. If you have any valuable things under the place, move them away.
Disassembling the camera for installation
1. Detach the dome cover from the camera
body by pressing the small buttons on
each side of the camera body.
2. Remove the dome protection film before
the installation.
Protection sticker
Protection
film
