DAC-10 Quick Setup with Final Cut Pro 4 (HD)
This setup guide will cover four specific areas:
A. Explanation of the DAC-10 dip switches
B. Configuration of the dip switches
C. Diagrams of typical cable connections
D. Initial Software configuration
A. Explanation of the DAC-10 Dip Switches
The DAC-10 has dip switches to customize the converter for your hardware and software.
The DAC-10 is sold throughout the world, so dip switch settings can be changed to
accommodate different regions and different firewire devices.
The diagram below explains what each dip switch controls within the DAC-10.
B. Configuration of the Dip Switches
Your DAC-10 dip switches have been preset for use with Macintosh computers. Your dip
switches should be set as follows:
Advertisement
Table of Contents
Related Manuals for Datavideo DAC-10
Summary of Contents for Datavideo DAC-10
- Page 1 A. Explanation of the DAC-10 Dip Switches The DAC-10 has dip switches to customize the converter for your hardware and software. The DAC-10 is sold throughout the world, so dip switch settings can be changed to accommodate different regions and different firewire devices.
- Page 2 Make sure your VCR or Analog source is connected to the inputs of the DAC-10. A 6-pin FireWire cable can be connected to the rear of the DAC-10. The opposite end should be connected to your 1394/connector on your computer.
- Page 3 Step 1 Power on your Mac computer. Step 2 Connect your Video and Audio cables. Step 3 Connect your DAC-10 to your computer via FireWire. (IEEE/1394 Cable) Step 4 Turn on your DAC-10 converter. Step 5 Launch Final Cut Pro.
