GENERAL ARRANGEMENT OF A BOAT S370NL (NLF), S420NL (NLF)

8
1
2
1. Buoyancy inflatable tube
2. Rubbing strake with splash guard
3. Safety handle
4. Fiberglass hull
5. Steering console
Fig. 42. General arrangement of a boat S370NL (NLF), S420NL (NLF).
75
9
3
5
7
4
6. Fiberglass step end
7. Double seat
8. Bow step plate
9. Bow locker
10. Folding navigation arch
