  • Page 1 ARIS UP PLUS PELLET STOVE Installation, use and maintenance page...

  • Page 2: Table Of Contents

    EDILKAMIN brand, called ARIS UP PLUS SERIAL NO.: Rating plate reference ARIS UP PLUS : Performance declaration: (DoP - EK no. 127) Moreover, the company hereby declares that: the ARIS UP PLUS wood pellet stoves satisfy the requirements of the following European directives:...

  • Page 3: Introduction And Readers Of This Manual

    First ignition is required for activation of the Edilkamin manual, observe local regulations. manufacturer warranty. The warranty is only valid in the The diagrams provided in this manual are for illustration country where the product was bought.

  • Page 4: Safety Information

    • Blocking the aeration vents and air intakes in the neither Edilkamin nor the retailer are liable for room. DO NOT BLOCK THE AERATION VENTS damage resulting from incorrect installation or OR FLUE. Risk of smoke returning into the room maintenance.

  • Page 5: Dimensions

    DIMENSIONS DIMENSIONS (cm) Combustion air Ø 4 cm aria Ø 40 mm combustione Smoke outlet Ø 4 cm aria Ø 8 cm Ø 80 mm combustione uscita fumi Ø 4 cm aria Hot air channel Ø 8 cm aria combustione Ø...

  • Page 6: Technical Data

    2,4 GHz Protection Fuse 4 AT, 250 Vac 5x20 The above data are illustrative and are drawn from the certification by a notified body. EDILKAMIN s.p.a. reserves the right to modify the product without notification in the interests of improvement. USER/INSTALLER...

  • Page 7: Unpacking

    UNPACKING PREPARATION AND UNPACKING TO REMOVE THE STOVE FROM THE PALLET The packaging materials are neither toxic nor noxious • Open the combustion chamber door using the and do not require special disposal. removable handle The end user is responsible for storing, disposing of •...

  • Page 8: Smoke Discharge Direction

    ORIENTATION OF THE SMOKE OUTLET SMOKE OUTLET The stove can have its smoke outlet pipe connected to the top or the rear. To use the rear smoke outlet, proceed as follows. Only perform work with the electrical power disconnected Use the smoke outlet Kit provided for the connection, as shown below Description Reference in Quantity...
  • Page 9 FUME DISCHARGE ARIS UP CERAMIC The CERAMIC version of ARIS is configured for con- necting the fume discharge pipe to the rear and to the top. WHATEVER SOLUTION IS USED TO CONNECT THE FUME OUTLET TO THE FLUE, IT IS NEC- ESSARY TO REMOVE THE LEFT-HAND REAR METAL SIDE (A) AND THE LEFT-HAND METAL FRAME (B).
  • Page 10 FUME DISCHARGE ARIS UP STEEL The STEEL version of ARIS is configured for connecting the fume discharge pipe to the rear and to the top. WHATEVER SOLUTION IS USED TO CONNECT THE FUME OUTLET TO THE FLUE, IT IS NECESSARY TO REMOVE THE LEFT-HAND REAR METAL SIDE (A - Fig.
  • Page 11 FUME DISCHARGE ARIS UP STONE The POTSTONE version of ARIS is configured for connecting the fume discharge pipe to the rear and to the top. WHATEVER SOLUTION IS USED TO CONNECT THE FUME OUTLET TO THE FLUE, IT IS NECESSARY TO REMOVE THE LEFT-HAND REAR METAL SIDE (A - Fig.

  • Page 12: Cladding Ceramic

    COVERING CERAMIC 1) VERSION WITH CERAMIC SIDES AND Fig. 1 The stove is delivered (Fig. 1) with the following external com- ponents already installed: • metal rear sides (A) • metal frames for fixing the ceramic side elements (B) • cast iron upper grille (C) The pieces indicated below are packaged separately.
  • Page 13 COVERING CERAMIC Fig. 4 fig. 4 Fix the upper horizontal ceramic element (E) to the upper cast REAR VIEW iron grid (C) with the two supplied screws M6x10 fig. 5 Fig. 5 Mount the vertical ceramic elements (D) onto the structure together with the metal frame brackets (B) previously detached from the stove.

  • Page 14: Cladding Steel

    COVERING STEEL 2) VERSION WITH STEEL SIDES AND PRO- fig. 7 FILES AND CERAMIC TOP Fig. 7 The stove is delivered with metal sides (A) and upper cast iron grille (C) already mounted. The parts indicated below are instead packed separately. •...

  • Page 15: Installation

    Contact the authorised Edilkamin Technical Assistance itself, or in any area with an explosive atmosphere. Centre. Any extraction fans operating in the same room or area as the product, may affect its draw.
  • Page 16 INSTALLATION FLUE SYSTEM • be certified, with a chimney plate if metal (Smoke duct, flue and chimney pot) • be of uniform cross section or vary in cross section This chapter has been drawn up pursuant to European only immediately after the outlet, not at some mid regulations EN 13384, EN 1443, EN 1856 and EN point of its length.
  • Page 17 INSTALLATION THE FLUE: EXTERNAL AIR INTAKE Further to the general prescriptions for the smoke duct In general, we suggest two ways to ensure a proper and flue, the flue: flow of combustion air. • must serve solely to discharge smoke •...
  • Page 18 (Bent, Split, Origami, Sharp). The instructions for connecting these vents are given in the manual provided with the vents. For Ø 8 cm ducting with Edilkamin Kit 12- 12bis • kit 12 for ducting into an adjacent room (pipe Ø 8 cm -3 m in length, B4 terminal vent;...

  • Page 19: Instructions For Use

    The electrical system must be compliant; check the operation of the earth in particular. Edilkamin is not responsible for malfunctions resulting from an improperly earthed system. The power line must be of adequate section for the power of the appliance.
  • Page 20 USER INSTRUCTIONS FIRST IGNITION (COMMISSIONING) PHAS- CARICAMENTO DEL PELLET NEL SERBATOIO • Make sure you have read and understood this Per accedere al serbatoio alzare il coperchio manual • Remove all flammable materials from the appliance (manuals, labels, etc.). In particular remove any When the stove is hot, DO NOT MAKE labels from the glass CONTACT between the pellet bag and the...
  • Page 21 USER INSTRUCTIONS OPERATION PHASES Further to the above operational procedures, the stove has the following phases Description. The access to and adjustment of these functions is described below: - Ignition (display reads ON ) Flame ignites and grows stable Mode Size settings This is the result of: MANUAL...
  • Page 22 • Open the bottom of the remote the intensity of use. Edilkamin and the retailer control and insert the 2 batteries in will not consider claims for battery life under any the indicated orientation.
  • Page 23 USER INSTRUCTIONS The display reads the POSSIBLE STATES described below: - OFF STATE The product is shutting down or is off in response to a manual switching off by using the ON/OFF button of the remote control or due to an external contact (crono, phone dialler) The display shows the current time, room temperature and the status in relation to which the product is OFF.
  • Page 24 USER INSTRUCTIONS USER CONTROLS (REMOTE CONTROL) Ventilation - ON/OFF The product is equipped with two fans, defined in the - Switch-on/switch-off control logic as fan 1 and 2, and displayed as positions - Manual mode setting 1 and 2 (see below). •...
  • Page 25 USER INSTRUCTIONS - Relax function - Stand by Natural convection function (without ventilation) with When the Stand by function is active, in automatic automatic power limiting. and crono modes, the product shuts off when the This function is available in all modes: automatic, temperature setpoint is reached and turns on again manual and crono.
  • Page 26 USER INSTRUCTIONS Crono The following screen will appear. Scroll to “ENABLE” When the Crono function is active, the user sets a (underlined) using the “+/-” buttons. temperature setpoint and a time zone for which that To enable the Crono function to 7 days a week or setpoint is specified.
  • Page 27 USER INSTRUCTIONS To combine one of the three temperatures To set the temperature setpoints (“TEMP” on to a time period (“SET” on the display), from the the display), from the Crono function, press the “OK” Crono function, press the “OK” button. The following button.
  • Page 28 USER INSTRUCTIONS The second screen (accessible by pressing the “OK” To view/change the settings (“CHANGE” on button from the first screen) allows you to set the start the display), from the Crono function, press the “OK” button. The following screen will appear. and end time of the time period matching the chosen Scroll to “CHANGE”...
  • Page 29 USER INSTRUCTIONS Night (deferred switching on/off) Load Pellets This function switches the product on/off after a set Allows you to load pellets after the screw feeder has emptied following a no-pellets alarm. period from activation of the function. Useful for the technician during commissioning. This is convenient if you go to bed and want the product Available only in the OFF state.
  • Page 30 USER INSTRUCTIONS Date/Time Beep Sets the current date/time. Allows you to enable/disable the beep. This displays the first time the remote control is To access the function from the main menu (as activated with the stove powered on, or by selecting indicated in the Menu section above), press the M the option in the menu.
  • Page 31 MAINTENANCE Before doing any maintenance, disconnect the appliance from the mains. Regular maintenance is essential for keeping the appliance in good working order. Failure to service the product properly will prevent it from working properly. Any problems due to failure to service the stove will void the warranty. DAILY MAINTENANCE These jobs should be done with the product off, cold and preferably disconnected from the mains.
  • Page 32 When the product is off and cold, remove the upper deflector (D), by pulling it towards you. The deflector is a component that is fragile and subject to wear, so neither Edilkamin nor the retailer can be held responsible for any breakage. USER/INSTALLER...

  • Page 33: Maintenance

    If the product is frequently used and the fume outlet Using non-original spare parts may damage the is on the top, decide with the technician whether to appliance and relieves Edilkamin of all liability for clean the inside of the elbow-union by removing the damage resulting therefrom.

  • Page 34: Troubleshooting

    TROUBLESHOOTING If problems occur, the product shuts itself off automatically. The display will show the reason (see below). Do not disconnect from the power supply. To start the product up again, allow the shutdown procedure to complete, then press the remote control’s ON/OFF button or the simplified ignition button.
  • Page 35 The battery symbol will appear on the remote control display if the battery is low. MAINTENANCE: A wrench symbol is shown on the display after 2000 hours of operation. The product is working, but it must be serviced by an authorised Edilkamin technician. USER/INSTALLER...
