SERIAL NO.: Rating plate reference Performance declaration: (DoP - EK n° 164): Rating plate reference Moreover, the company hereby declares that: the EVIA wood pellet stove satisfies the requirements of the following European directives: 2014/35/EC - Low Voltage Directive 2014/30/EC - Electromagnetic Compatibility Directive...
Page 3
European regulations. For the will operate to best effect and in complete safety. installation, and for anything not specifically indicated in the Commissioning is required for activation of the Edilkamin manual, observe local regulations. manufacturer warranty. The warranty is only valid in the The diagrams provided in this manual are for illustration country where the product was bought.
• Use of the product as a support or ladder. DO to the warranty certificate inside the product: NOT CLIMB ONTO THE PRODUCT OR USE specifically, neither Edilkamin nor the retailer IT AS A SUPPORT. Risk of damage and injury. are liable for damage resulting from incorrect •...
Page 5
DIMENSIONS DIMENSIONS (cm) Combustion Ingresso aria air Ø 4 cm combustione Ø 4 cm maschio Smoke outlet with Eventuale uscita optional Ø 8 cm fumi posteriore Smoke outlet with outlet male 10,3 Uscita fumi di serie Ø 8 cm female Ø...
Page 6
Fuse 4 AT 250 V AC 5x20 The above data is for guidance only and was measured during certification by a notified body. EDILKAMIN s.p.a. reserves the right to modify the product without notification in the interests of improvement. USER/INSTALLER...
UNPACKING PREPARATION AND UNPACKING PACKAGING The packaging materials are neither toxic nor noxious The delivery consists of two packages: and do not require special disposal. • one containing the stove frame The user is responsible for storing, disposing of and •...
Page 8
UNPACKING TO REMOVE THE STOVE FROM THE PALLET To remove the stove from the pallet you must (see the figures below): 1. remove the cardboard 2. open the attractive door and undo the screws with the washer in front 3. remove the bracket (screwed) on the rear. DO NOT TRY REMOVING THE STOVE FROM THE PALLET BEFORE HAVING UNDONE THE SCREWS ON THE FRONT, VISIBLE AFTER HAVING OPENED THE ATTRACTIVE DOOR INSTALLER...
Page 9
UNPACKING Detail of the screws with washer in front Detail of the bracket screwed on the rear INSTALLER...
Page 10
ORIENTATION OF THE SMOKE OUTLET SMOKE OUTLET The stove is delivered with the fume discharge pipe outlet on the top. To use the rear smoke outlet we provide an optional which can be found in our stores. The kit includes the instructions. The operation must be carried out by a technician. INSTALLER...
Contact the authorised Edilkamin Technical Assistance Any extraction fans operating in the same room or Centre. area as the product, may affect its draught.
Page 12
INSTALLATION FLUE SYSTEM THE FUMES DUCT (Fumes duct, flue and chimney pot) Further to the general prescriptions for the fumes duct This chapter has been drawn up pursuant to European and flue, the fumes duct: regulations EN 13384, EN 1443, EN 1856 and EN •...
Page 13
INSTALLATION THE FLUE: EXTERNAL AIR INTAKE Further to the general prescriptions for the fumes duct In general, we suggest two ways to ensure a proper and flue, the flue: flow of combustion air. • must only be used for discharging fumes •...
Page 14
The electrical system must be compliant; check the operation of the earth in particular. Edilkamin is not responsible for malfunctions resulting from an improperly earthed system. The power line must be of adequate section for the power of the appliance.
Page 15
COVER ADDITIONAL INSTRUCTIONS FOR COVERING INSTALLATION Make sure to “push” the top until the end stop, loosening the two fixing screws, re-tightening them back as shown in the illustration below, before installing covering to the stove structure. slots must be placed on the FIXING SCREWS...
Page 16
COVER To assembly the cladding, proceed as follows. The figure shows the right side. Prepare the side by fastening the plate. Right-hand side Adjust feet making them flush with the insert (see image), before sides fitting. Feet INSTALLER...
Page 17
COVER Insert the side on the pins on the bottom Screw the side on the top. Place (without fastening) the screws (4) provided. Fasten the two screws (V). Fasten the screws (4). Repeat the operations to mount the other side panel. INSTALLER...
Page 18
COVER Possible adjustments To adjust any misalignments, in addition to adjusting screws (V) and (4), remove the side panel and regulate the screws (R) of the plate on the bottom. screws (R) of the plate INSTALLER...
USER INSTRUCTIONS FIRST IGNITION (COMMISSIONING) PHASES LOADING THE PELLETS INTO THE TANK • Make sure you have read and understood this To access the tank, open the lid*. manual • Remove all flammable materials from the appliance (manuals, labels, etc.). In particular remove any labels from the glass When the stove is hot, DO NOT REST the •...
Page 20
USER INSTRUCTIONS OPERATION INTERFACE The user interface is the remote control but, if this is not available, you can control the stove with the button on Description. The access to and adjustment of these the back (see figure below) functions is described below: 1.
Page 21
O N / O F F since it depends on both the type of batteries and button the intensity of use. Edilkamin and the reseller will not consider claims for battery life under any circumstances. If the battery charge is low, a warning displays at the top left (see the paragraph on “If problems arise”).
Page 22
USER INSTRUCTIONS The display reads the POSSIBLE STATES described below: - OFF STATE The product is “deactivated” and will not produce heat due to manual switching off using the ON/OFF button on the remote control or due to an external contact (crono, phone dialler) The display shows the current time, room temperature and the status in relation to which the product is OFF.
Page 23
USER INSTRUCTIONS USER CONTROLS (REMOTE CONTROL) Ventilation setting - ON/OFF Follow the instructions below to manually regulate the - Switch-on/switch-off power levels of the fan. - Manual mode setting Press “OK” once • Setting the power The fan setting displays, next to the blade symbol •...
Page 24
USER INSTRUCTIONS Relax Function Stand by Natural convection function (without ventilation) with When the Stand by function is active, in automatic automatic power limiting. and crono mode, the product shuts off when the This function is available in all modes: automatic, temperature setpoint is reached and turns on again manual and crono.
Page 25
USER INSTRUCTIONS Crono The following screen will appear. Scroll to “ENABLE” When the Crono function is active, the user sets a (underlined) using the “+/-” buttons. temperature setpoint and a time zone for which that To enable the Crono function to 7 days a week or setpoint is specified.
Page 26
USER INSTRUCTIONS To combine one of the three temperatures To set the temperature setpoints (“TEMP” on to a time period (“SET” on the display), from the the display), from the Crono function, press the “OK” Crono function, press the “OK” button. The following button.
Page 27
USER INSTRUCTIONS The second screen (accessible by pressing the “OK” To view/change the settings (“CHANGE” on button from the first screen) allows you to set the start the display), from the Crono function, press the “OK” button. The following screen will appear. and end time of the time period matching the chosen Scroll to “CHANGE”...
Page 28
USER INSTRUCTIONS Night (deferred switching on/off) Load Pellets This function switches the product on/off after a set Allows you to load pellets after the screw feeder has period from activation of the function. emptied following a no-pellets alarm. This is convenient if you go to bed and want the product Useful for the technician during commissioning.
Page 29
USER INSTRUCTIONS Date/Time Beep Sets the current date/time. Allows you to enable/disable the beep. This displays the first time the remote control is To access the function from the main menu (as activated with the stove powered on, or by selecting indicated in the Menu section above), press the M the option in the menu.
MAINTENANCE Before doing any maintenance, disconnect the appliance from the mains. Regular maintenance essential keeping the appliance in good working order. Failure to service the stove will prevent it FIG. A from working properly. Any problems due to failure to service the stove will void the warranty.
Page 31
MAINTENANCE WEEKLY MAINTENANCE • Extract the deflector (3 - fig. C) and tip the residues into the ash tray. The ceiling panel is subject to wear; the manufacturer is not responsible for breakage, especially if this occurs when its is being removed or repositioned. After normal cleaning, make sure the burning pot is PROPERLY SEATED (A - fig.
Page 32
For any spare parts, contact your dealer or technician. flue every 3 months. Using non-original spare parts may damage the appliance and relieves Edilkamin of all liability for You should clean the chimney system at least once a damage resulting such use.
TROUBLESHOOTING If problems occur, the product shuts itself off automatically. The display will show the reason (see below). Do not disconnect from the power supply. To start the appliance up again, allow the shutdown procedure to complete, then press the ON/OFF button on the remote control or the simplified ignition button.
Page 34
The battery symbol displays on the remote control display if the battery is low. MAINTENANCE: A wrench symbol is shown on the display after 2000 hours of operation. The product is working, but it must be serviced by an authorised Edilkamin technician. USER...
Page 36
*941885-GB* w w w . e d i l k a m i n . c o m code 941885-GB 04.18/B...
