- Page 1 SLIDE Pellet stove Installation, use and maintenance...
-
Page 2: Table Of Contents
SERIAL NUMBER: Nameplate reference Performance declaration: (DoP - EK n° 140): Nameplate reference And also declares that: the SLIDE wood pellet stove satisfies the requirements of the following European directives: 2014/35/EC - Low Voltage Directive 2014/30/EC - Electromagnetic Compatibility Directive... - Page 3 Proper commissioning is required for activation of the Edilkamin warranty. The warranty is only valid in the country of sale of the product. If the appliance is not commissioned by an authorised technician, Edilkamin will not provide warranty service.
-
Page 4: Safety Information
safety infoRMation • The appliance is not designed for use by people, PLACE DRYING RACKS WITHIN THE SAFETY including children, with limited physical, sensory CLEARANCE. Keep flammable fluids away from and mental capacities. the product. Fire hazard. • The appliance is not intended to be used for • blocking the aeration vents and air intakes in the cooking. -
Page 5: General Information
geneRal infoRMation DIMENSIONS (cm) Ø 8 cm outlet Ø 4 cm combustion Ø 8 cm outlet... -
Page 6: Electrical Specifications
Logic board protection Fuse 4 AT, 250 Vac 5x20 The above data are illustrative and are drawn from the certification by a notified body. EDILKAMIN s.p.a. reserves the right to modify the product without notification in the interests of improvement. -
Page 7: Installation
installation PRePaRation anD UnPacKing installing tHe lining The packaging materials are neither toxic nor noxious Proceed as follows (refer to the figures): and do not require special disposal. • To remove the stove from the pallet: remove the The user is responsible for storing, disposing or and screws and rear bracket;... - Page 8 installation To remove the stove from the pallet: remove the screws and rear bracket; take the side panels off to remove the front screws.
- Page 9 installation Fit the interlocking side panels and screw down the bolts on the back...
- Page 10 installation Position the top, after having inserted the 5 rubber dampers, by slotting it into the two pins (arrows)
- Page 11 • Level the appliance wind, its safety equipment may switch the stove off. • The appliance may not be installed in a bedroom, Contact the authorised Edilkamin Technical Assistance bathroom or in the same room as other equipment Centre. which draws air for combustion from the room itself, or in any area with an explosive atmosphere.
- Page 12 installation flUe systeM • be certified, with a chimney plate if metal (Fumes duct, flue and chimney pot) • be of uniform cross section or vary in cross section Thsi chapter has been drawn up pursuant to European only immediately after the outlet, not at some mid regulations EN 13384, EN 1443, EN 1856 and EN point of its length 1457.
- Page 13 installation tHe flUe: eXteRnal aiR intaKe Further to the general prescriptions for the fumes duct In general, we suggest two ways for ensuring a proper and flue, the flue: flow of combustion air. • must serve solely to exhaust fumes • must be correctly sized to satisfy the requirements indirect air intake of fumes exhaust (EN 13384-1)
- Page 14 (the power socket must be located in an Pellet tanK easy to access position) Slide the top to load the pellets The stove is equipped with an electrical power cord 1) When doing so, Do not rest or connection to a 230V 50 Hz socket, preferably with the bag of pallets on the top electromagnetic cutout.
- Page 15 UseR instRUctions oPeRation PHases Further to the above operational procedures, the stove Description. has the following phases The access to and adjustment of these functions is described on page: - ignition (display reads ON ) Flame ignites and grows stable Method Settings This is the result of:...
-
Page 16: Remote Control
• Open the back of the remote and insert the use. Edilkamin and the reseller will not consider two batteries in the indicated orientation. claims for battery life under any circumstances. If •... - Page 17 UseR instRUctions The display reads the Possible states described below: - off state The stove is shutting off or is off in response to operation of the remote control’s ON/OFF key or an external contact (crono, phone dialler) The display shows the current time, room temperature and the status in relation to which the stove is OFF.
- Page 18 UseR instRUctions UseR contRols (ReMote contRol) In automatic: Room temperature setting - on/off Set the temperature setpoint (Set) with the “+” and “-“ buttons. - switch-on/switch-off Ventilation setting Press “OK” once - Manual mode setting The fan setting displays, next to the blade symbol •...
- Page 19 UseR instRUctions - Relax function - stand by When the Stand by function is active, in automatic and Natural convection function with automatic power timer modes, the stove shuts off when the temperature limiting. setpoint is reached and turns on again when the This function is available in all modes: automatic, temperature drops.
- Page 20 UseR instRUctions - crono NOTE When the Crono function is active, the user sets a the ignition times are indicated by the fact that temperature setpoint and a time zone for each day of the dots are black. In zones with white dots, the the week for which that setpoint is specified.
- Page 21 UseR instRUctions - night load Pellets This function shuts the appliance down after a given Loads pellets, for example when the screw feeder is number of hours of activation of the function itself. empty. This is convenient if you go to bed and want the stove Used by the technician during commissioning.
- Page 22 UseR instRUctions Date/time info Sets the current date/time. These readings should only be done when requested This displays the first time the remote is activated with by the technician. the stove powered on, or by selecting the option in the The technician understands the diagnostic meaning of menu.
-
Page 23: Maintenance
Maintenance before doing any maintenance, disconnect the appliance from the mains. Regular maintenance essential keeping the appliance in good working order. failURe to seRVice tHe stoVe Will PReVent it fRoM WoRKing PRoPeRly. any problems due to failure to service the stove will void the warranty. - Page 24 Maintenance WeeKly Maintenance Extract the ceiling panel (3 - fig. C) and drop the residues into the ash tray. The ceiling panel is subject to wear; the manufacturer is not responsible for breakage, especially if this occurs when its is being removed or repositioned. Once you have finished cleaning the stove, make sure the grate is PROPERLY SEATED (A - fig.
- Page 25 For any spare parts, contact your reseller or technician. months. Using non-original spare parts may damage the appliance and relieves Edilkamin of all liability for You should clean the chimney system at least once a damage resulting therefrom. year (check local regulations for details).
-
Page 26: Troubleshooting
tRoUblesHooting if problems occur, the stove shuts itself off automatically. the display will show the reason (see below). Do not disconnect the electrical power supply. to start the product up again, allow the shutdown procedure to complete, then press the remote control's ON/OFF button or the simplified ignition button. - Page 27 The battery symbol displays on the remote’s display if the battery is low. Maintenance: A wrench symbol is shown on the display after 2000 hours of operation. The product is working, but it must be serviced by an authorised Edilkamin technician.
- Page 28 w w w . e d i l k a m i n . c o m cod. 941296-GB 04.16/B...
