MYRNA
MYRNA Q
PELLET STOVE
MYRNA
MYRNA Q
UK Installation, use and maintenance
page
2

Advertisement

loading
Need help?

Need help?

Do you have a question about the MYRNA and is the answer not in the manual?

Questions and answers

Related Manuals for EdilKamin MYRNA

Summary of Contents for EdilKamin MYRNA

  • Page 1 MYRNA MYRNA Q PELLET STOVE MYRNA MYRNA Q UK Installation, use and maintenance page...

  • Page 2: Table Of Contents

    In the event of problems In the event of problems The original language of this manual is Italian EDILKAMIN S.p.A., with registered offices in Via Vincenzo Monti 47 - 20123 Milan - tax code and VAT number 00192220192 Declares, under its sole responsibility, that:...
  • Page 3 • the declaration of conformity given to you by the installer. www.edilkamin.com. The warranty conditions are given in the warranty certificate Readers of this manual accompanying the product.

  • Page 4: Safety Information

    CLIMB ONTO THE PRODUCT OR USE IT AS A the warranty certificate inside the product: neither SUPPORT. Risk of damage and injury. Edilkamin nor the reseller are liable for damage • use of the stove with the hearth open. DO NOT resulting from incorrect installation or maintenance.

  • Page 5: General Information (Dimensions,Technical Data)

    GENERAL INFORMATION Dimensions (cm) MYRNA Smoke outlet Ø 8 cm Combustion Ø 4 cm 54,5 54,5 MYRNA Q Smoke outlet Ø 8 cm 27,3 27,3 Combustion Ø 4 cm 54,5 54,5 USER/INSTALLER...
  • Page 6 Power absorbed in stand by Power absorption during ignition 365 W Remote control frequency (provided) 2,4 GHz Protection Fusibile 4 AT, 250 Vac 5x20 EDILKAMIN s.p.a. reserves the right to modify the product without notification in the inte- rests of improvement. USER/INSTALLER...

  • Page 7: Unpacking

    UNPACKING PREPARATION AND UNPACKING The packaging materials are neither toxic nor noxious The packaging materials are neither toxic nor noxious and do not require special disposal. and do not require special disposal. The user is responsible for storing, disposing of and The user is responsible for storing, disposing of and recycling them in a regulatory fashion.
  • Page 8 UNPACKING DO NOT REMOVE THE PRODUCT FROM THE PALLET BEFORE LOOSENING THE SCREWS. 1- put off the flancs 2 - open the door 3- put off composant A 4 - screw out the 4 screws V INDICATIVE DRAWINGS, NOT ALWAYS REFERRING TO THE SPECIFIC MODEL. INSTALLER...

  • Page 9: Cover

    COVER COVER’S CONTENT - C1: ceramic top front - C2: ceramic cover pellet - F: front panel INDICATIVE DRAWINGS, NOT ALWAYS REFERRING TO THE SPECIFIC MODEL. INSTALLER...
  • Page 10 COVER FITTING OF THE CERAMIC TOP FRONT 1) Remove the metal front panel (A) 2) Fix loosely the screw (V) to the ceramic Put the ceramic with the screw on the top. Fix the screw. INDICATIVE DRAWINGS, NOT ALWAYS REFERRING TO THE SPECIFIC MODEL. INSTALLER...
  • Page 11 COVER FITTING OF THE CERAMIC COVER PELLET (V1) Take the ceramic (C2) put it close to the open cover (V2) pellet fix it by hand with the 4 screws (V1). (C2) (V1) (V1) FROM THE REAR NOTE BE CAREFULL TO PUT AS SHOWED HERE FROM THE REAR FITTING OF THE FRONT PANEL (F) Fix by hand the composant A to the ceramic...
  • Page 12 COVER The result is showed at the picture below. INDICATIVE DRAWINGS, NOT ALWAYS REFERRING TO THE SPECIFIC MODEL. INSTALLER...

  • Page 13: Installation

    • The appliance may not be installed in a bedroom, Contact the authorised Edilkamin Technical Assistance bathroom or in the same room as other equipment Centre. which draws air for combustion from the room itself, or in any area with an explosive atmosphere.
  • Page 14 INSTALLATION FLUE SYSTEM FLUE SYSTEM EXTERNAL AIR INTAKE ( ( Fumes duct, flue and chimney pot Fumes duct, flue and chimney pot) ) In general, we suggest two ways for ensuring a proper Thsi chapter has been drawn up pursuant to European flow of combustion air.
  • Page 15 INSTALLATION INTUBATED SYSTEM INTUBATED SYSTEM: Further to the general prescriptions for the fumes duct and flue, the intubated system: • must operate in negative pressure; • must be open to inspection • must observe local regulations. THE CHIMNEY POT THE CHIMNEY POT •...
  • Page 16 INSTALLATION EXTERNAL AIR INTAKE In general, we suggest two ways for ensuring a proper flow of combustion air. Indirect air intake Install an intake at floor level with effective area (net of the mesh or other protective equipment) of at least 80 (10 cm dia.).
  • Page 17 The electrical system must be compliant; check the operation of the earth in particular. Edilkamin is not responsible for malfunctions resulting from an improperly earthed system. The power line must be of adequate section for the fuse power of the appliance.

  • Page 18: User Instructions

    USER INSTRUCTIONS FIRST IGNITION PROCEDURE LOADING THE PELLETS INTO THE PELLET • • Make sure you have read and understood this Make sure you have read and understood this TANK manual manual To access the tank, open the lid. • • Remove all flammable materials from the appliance Remove all flammable materials from the appliance (manuals, labels, etc).
  • Page 19 • SAVE PANEL: panel used for the on/off functions; power setting By purchasing the Edilkamin optional elements included in the range: • UMTS MODEM: used for managing a few functions, even outside of home, by means of a mobile telephone By purchasing the non-Edilkamin optional elements: •...
  • Page 20 (operations not protected by password) • installer (operations with dedicated password because any errors can jeopardise the product’s operations and SECURITY) • Edilkamin technical assistance centre (operations with dedicated password because any errors can jeopardise the product’s operations and SECURITY) USER...
  • Page 21 This only refers to the remote control, not the product itself. In normal use, the remote control’s batteries should last a year. This duration is for illustrative purposes only. Edilkamin and the reseller will not consider claims for battery life under any circumstances. RELAX...
  • Page 22 USER INSTRUCTIONS: REMOTE CONTROL current room temperature target room temperature Bluetooth communication present between the stove and the circuit board. If there is no communica- tion, the symbol disappears. Wi-Fi communication of the product towards the router. If there is no communication, the symbol disap- pears.
  • Page 23 USER INSTRUCTIONS: REMOTE CONTROL Visualisation of the status of the fan(s). If the activation fume temperature has not been reached, it will not display any symbol. SPEED OFF SPEED 1 SPEED 2 SPEED 3 SPEED 4 SPEED 5 AUTOMATIC The stand-by function (where present and active) has caused the product to switch off. It does NOT indicate that the function is enabled.
  • Page 24 USER INSTRUCTIONS POSSIBLE STATUSES of the product - OFF STATE The product is “deactivated” and will not produce heat due to manual switching off using the ON/OFF button on the remote control or due to an external contact (timer, telephone dialler). From the OFF page, press the ON/OFF button for 3 seconds to access the ON page.
  • Page 25 USER INSTRUCTIONS POWER ON/POWER OFF These operations will take a few minutes, during which the flame must appear or switch off. Simply wait without taking any action. The ON/OFF button is used to manually start the on or off phase. During the switch-on, the display will show the status (CLEANING;...
  • Page 26 USER INSTRUCTIONS AUTOMATIC and MANUAL setting Press the AUTO/MAN button for a few seconds to switch from manual to automatic mode or vice versa. AUTOMATIC MANUAL In AUTOMATIC mode: Setting of the room temperature (read by the remote control, which should be located in the room where the product is installed).
  • Page 27 USER INSTRUCTIONS - FAN ADJUSTMENT The setting can be made with the stove turned OFF or ON. If the backlight is switched off, it can be activated by pressing any button. Pressing the button will make SET flash and, instead of the room set-point, the number of the fan being modified will appear (F1).
  • Page 28 USER INSTRUCTIONS - RELAX FUNCTION Natural convection function (without ventilation) with automatic power limiting. This function is available in all modes: automatic, manual and timer-based. Press and hold the button to activate the Relax function. Its activation on the display will be signalled by the arrow relative to the Relax button. Prolonged pressing of the button will deactivate the function.
  • Page 29 USER INSTRUCTIONS - AIRKARE FUNCTION This function is available as a standard feature on certain models and as an optional feature on other models: check which model you have. The function, if available, can be activated with the stove either on or off, in any mode (except in alarm mode). The airKare can be activated by pressing the dedicated button Its activation on the display will be signalled by the arrow relative to the airKare button.
  • Page 30 USER INSTRUCTIONS - EASY TIMER (deferred switching on/off) This function switches the product on/off after a set period from activation of the function. This is convenient if you go to bed and want the product to switch on/off after a few hours (maximum 12 hours). The Easy Timer function can be activated by pressing the dedicated button.
  • Page 31 USER INSTRUCTIONS TIMER Timer regulation is possible by MENU If the product is in automatic mode, the product works at room temperature otherwise it works with the power. Pressing the button allows for switching from Temperature Timer to Power Timer and vice versa. Pressing the button activates or deactivates the timer (pre-programmed from the app or remote control).
  • Page 32 USER INSTRUCTIONS - MENU It can be accessed by pressing the button and the first Menu item will appear. The menu items can be scrolled with the buttons and the item can be entered with the button. The menu items appear in the following order: 01 STAND-BY 02 PELLET LOAD 03 CHRONO PROG.
  • Page 33 USER INSTRUCTIONS - STAND-BY When the Stand-by function is active, in the automatic and timer modes, the product switches off once the temperature set-point is reached and turns on again when the room temperature drops below the chosen value. When the Stand-by function is not active, the product sets itself to minimum power when the temperature set-point is reached.
  • Page 34 USER INSTRUCTIONS Pressing the button with the value ON activates the function and the display will propose to choose how many minutes must pass before the devices switches off in stand-by mode. (es: 5 minutes) buttons can be used to modify the time and the button to confirm.
  • Page 35 USER INSTRUCTIONS - PELLET LOAD Allows you to load pellets after the screw feeder has emptied. Useful for the technician during the initial start-up. Available only in the OFF status. Any attempt to activate the function in other statuses will not be allowed. To access the function from the main menu (as indicated in the Menu paragraph above), press the M button.
  • Page 36 USER INSTRUCTIONS - CHRONO PROG. (TIMER) To access the function from the main menu (as indicated in the Menu section above), press the MENU button. The menu items can be scrolled with the buttons and the item can be entered with the button.
  • Page 37 USER INSTRUCTIONS Choose the day of the week by scrolling the buttons (you will simultaneously see the programme for that day) and confirm with the button. BUTTON OK SAVE The cursor (rectangular and 2 pixels wide) positions itself on 00:00. The time at the top RH shows the start of the time slot.
  • Page 38 USER INSTRUCTIONS buttons can be used to modify the temperature levels (OFF – T1 and T2) or the power levels (OFF – P1 and P5). After reaching 23:30 you must go backwards. If you shift by pressing and holding the buttons for more than 2", you copy the previous level onto the next level with a 1/2 h frequency per second.
  • Page 39 USER INSTRUCTIONS The day of the week will flash again and you can move to the next day Confirm with the following button Pressing the button briefly allows you to exit the programming, but the programme will not activate. To activate it, you must briefly press the button again from the main page.
  • Page 40 USER INSTRUCTIONS To access the function from the main menu (as indicated in the Menu section above), press the MENU button. The menu items can be scrolled with the buttons and the item can be entered with the button. After entering the T1-T2 function, the display will show the name of the function on the first line of the status bar and the current value of T1 on the second line.
  • Page 41 USER INSTRUCTIONS - DATE AND HOUR (TIME) Can be used to set the current date and time. To access the function from the main menu (as indicated in the Menu section above), press the MENU button. The menu items can be scrolled with the buttons and the item can be entered with the button.
  • Page 42 USER INSTRUCTIONS - °C/°F SETTING of the temperature scale (centigrade or Fahrenheit degrees) To access the function from the main menu (as indicated in the Menu section above), press the MENU button. You can scroll the menu items with the buttons and enter the item with the following button After entering the °C/°F function, the name of the function appears on the first line of the status bar and the current value on the second line.
  • Page 43 USER INSTRUCTIONS - LANGUAGE SETTING Selects the language. To access the function from the main menu (as indicated in the Menu section above), press the MENU button. You can scroll the menu items with the buttons and enter the item with the following button After entering the Language Menu item, the name of the function appears on the first line of the status bar and the current value on the second line ITALIANO that means Italian.
  • Page 44 USER INSTRUCTIONS - DISPLAY It allows you to choose the background of the display, USER...
  • Page 45 USER INSTRUCTIONS - INFO These readings should only be done when requested by the technician. The technician understands the diagnostic meaning of the messages and values, and may ask you to read them to him/her if you experience problems. To access the function from the main menu (as indicated in the Menu paragraph above), press the MENU button. You can scroll the menu items with the buttons.
  • Page 46 USER INSTRUCTIONS - DATA Information of the product’s operation log can be scrolled with the buttons. To access the function from the main menu (as indicated in the Menu paragraph above), press the MENU button. The menu items can be scrolled with the buttons and the item can be entered with the button.
  • Page 47 USER INSTRUCTIONS - ALARM LOG Information of the product’s operation log can be scrolled with the buttons. The alarms are arranged from the most recent to the oldest. ALARMS ALARMS ALARMS Exit with the following button - SCREW FEEDER ON-OFF FOR THE TECHNICIAN ONLY (ON INDICATION OF THE AFTER-SALES DEPARTMENT) AUGER MOT.
  • Page 48 USER INSTRUCTIONS - TECHNICAL MENU (for TECHNICIANS ONLY) Accessible only to an authorised technician with the appropriate password. NOTES You must enter with the installer password (1111) and access the inappropriate changes can cause installer parameters/settings only the product to seize up Flame type (INST) Pellet type (INST) Chimney sweep function (INST)
  • Page 49 USER INSTRUCTIONS - PELLET TYPE You can scroll the Technical Menu items with the buttons until you reach “PELLET TYPE” PELLET TYPE You can enter the Pellet Type setting with the following button and modify the value with the buttons. Use the button to exit and return to the Technical Menu INSTALLER...
  • Page 50 USER INSTRUCTIONS - CHIMNEY SWEEP FUNCTION (ONLY WITH THE PRODUCT ON) It can be used to conduct the requested checks agreed upon with the technician Scroll between the Nominal (Max) or Minimum (Min) function using the buttons and modify the value from OFF to ON with the buttons.
  • Page 51 USER INSTRUCTIONS - PARAMETERS PLEASE REFER SERVICE SUGGESTIONS You can scroll the Technical Menu items with the buttons until you reach “PARAMETERS”. PARAMETERS Enter the Parameters section with the button: the first parameter will be displayed. PLT LEVEL SENSOR Scroll the parameters with the buttons and modify the value with the buttons.
  • Page 52 USER INSTRUCTIONS: SAVE PANEL SAVE PANEL network present “power” button O n - O f f button SAVE PANEL can temporarily make up for the absence of a remote control or smartphone, or other product management systems. Controls the product starting from the pressing of the buttons. When the remote control or smartphone re-establishes the communication and sends a command to the product, the remote control or smartphone will once again resume control of the product.
  • Page 53 USER INSTRUCTIONS: SAVE PANEL The three LEDs on the left indicate the status of the product associated with the display. Panel without control unit Active: LED1 (network present) Stove off Digits = “OFF” active: LED1 Stove being switched on Digits = “ON” active: LED1 and LED2 Stove running Digits = “ON”...

  • Page 54: Maintenance

    MAINTENANCE Before doing any maintenance, disconnect the appliance from the mains. Regular maintenance is essential to keeping the appliance in good working order. FAILURE TO SERVICE THE STOVE WILL PREVENT IT FROM WORKING PROPERLY. Any problems due to failure to service the stove will void the warranty. - Any unauthorized modification is prohibited DAILY MAINTENANCE These jobs should be done with the product off, cold and preferably disconnected from the...
  • Page 55 MAINTENANCE 1. Open the combustion chamber door (P) using the removable handle provided. 2. The burning pot (A) slips into position in its housing. Empty the ash tray (B) and burning pot into a non-flammable container (the ashes may still contain embers and/or hot parts) or vacuum if cold. Vacuum out the interior of the combustion chamber, the bed, and the compartment around the burning pot into which the ash falls.
  • Page 56 Using non-original spare parts may damage the You should clean the chimney system at least once a appliance and relieves Edilkamin of all liability for year (check local regulations for details). damage resulting therefrom. If you fail to regularly clean and inspect the system,...

  • Page 57: In The Event Of Problems

    IN THE EVENT OF PROBLEMS If problems occur, the product shuts itself off automatically. The display will show the reason (see below). Do not disconnect from the power supply. To restart the product, wait for the switch-off sequence to terminate and then press the ON/OFF button of the remote control or the simplified switch-on button.
  • Page 58 IN THE EVENT OF PROBLEMS MESSAGE PROBLEM SOLUTION • Check that the combustion chamber door is closed displays when the combustion • Check the regular maintenance of the product air intake is below the set level • Check that smoke discharge and combustion air ducts are clean.
  • Page 59 IN THE EVENT OF PROBLEMS MESSAGE PROBLEM SOLUTION Room temperature probe failure. The product is operating • Contact the technician in manual mode. Ducting room temperature probe (if present) fault. The • Contact the technician product is operating in manual mode.
  • Page 60 MAINTENANCE: A spanner symbol will appear on the display after 2,000 hours of operation. The product is working, but it must be serviced by an authorised Edilkamin technician. LACK OF COMMUNICATION: In case of a prolonged lack of communication between the stove and the remote control, the Bluetooth transmission icon will disappear as well as the icons transmitted by the circuit board to the remote control.
  • Page 61 IN THE EVENT OF PROBLEMS PELLETS RESERVE INDICATOR: The function is only available if the pellet level sensor is installed and has been activated. When the level sensor intervenes, the circuit board emits a single “beep” (in any switch-on or work status) and the moving reserve symbol will appear on the display.
  • Page 62 IN THE EVENT OF PROBLEMS After an interval of roughly 20/30 minutes, which varies depending on the model, the stove switches off due to a shortage of pellets. If the user reloads the stove before the start of the switch-off procedure, the symbol disappears and the stove resumes its normal operation.
