2.4 DESCRIPTION OF FUNCTIONING
STATES
Below find a list of boiler functioning states that
appear on the multifunction display (24) by
Display (6)

Description of functioning states

Summer functioning mode without request in progress.
SUMMER
Boiler in stand-by for domestic hot water request.
Winter functioning mode without request in progress.
WINTER
Boiler in stand-by for domestic hot water or central heating request.
Domestic hot water mode in progress.
DHW ON
Boiler functioning, domestic hot water heating in progress.
Central heating mode in progress.
CH ON
Boiler functioning, central heating in progress.
Antifreeze mode in progress.
F3
Boiler functioning to restore the minimum safety temperature against boiler freezing.
CAR OFF Remote Control (Optional) off.
With domestic hot water priority disabled (indicator 15 off), the boiler only functions in room central heating mode for
duration of 1 hour, however keeping the domestic hot water at minimum temperature (20°C), after which the boiler
DHW OFF goes back to the normal functioning, previously set.
In the case of use with Super CAR in concomitance with the functioning period in reduced D.H.W. Timer mode, DHW
OFF will appear on the display and indicators 15 and 2 switch off (see Super CAR instructions manual).
Postventilation in progress.
F4
Fan in function after a request for domestic hot water or central heating in order to evacuate residual flue gas.
Postcirculation in progress.
F5
Pump in function after a request for domestic hot water or central heating in order to cool the primary circuit.
With Remote Control (Optional) or room thermostat (TA) (Optional) in block, the boiler functions all the same in central
P33 heating mode. (Can be activated through menu "M3". It allows you to activate the central heating even if the Remote
Control or TA are out of order).
Reset attempts finished
STOP Wait for 1 hour to re-acquire 1 attempt.
(Error code 08).
Anomaly present with relative error code.
ERR xx
The boiler does not work. (see troubleshooting paragraph).
When the domestic hot water temperature selector switch is turned (1 Fig. 2-1) it displays the control status of the domes-
SET
tic hot water temperature in progress.
When the central heating temperature selector switch is turned (1 Fig. 2-1) it displays the control status of the boiler flow
SET
temperature for room central heating.
In the presence of the external probe (optional) replace the "SET" item.
SET
The value that appears is the correction of the flow temperature with respect to the functioning curve set by the external
probe. See OFFSET on external probe graphics (Fig. 1-6).
System deaeration in progress.
F8
During this phase, which lasts 18 hours, the boiler circulator pump is started at preset intervals, thus allowing deaeration
of the central heating system.
Only in the case of use with Super CAR, does it allow to activate the anti-legionella function, which takes the temperature
F9
of the water in the storage tank to 65°C for 15 minutes. (see Super CAR instruction manual).
means of the indicator (6) with a brief descrip-
tion. Refer to the instruction book for a complete
explanation.
