- Page 1 USER’S MANUAL FROST FREE REFRIGERATOR Models : TFF210WNTAM TFF210SNTAM TFF240WNTAM TFF240SNTAM TFF270WNTAM TFF270SNTAM To ensure proper use of the appliance and your safety, please read the following user manual completely before use.
- Page 2 Follow the operating instructions and safety notices in this manual. If any trouble arise, do not attempt to fi x it yourself. Please contact TECO service on 1300 660 037 (8:30am - 4pm Mon~Fri AEST). This refrigerator is designed and approved for use with fl ammable R600a refrigerant.
-
Page 3: Table Of Contents
◊ Frost Free ◊ Internal LED Lighting ◊ Electronic Temp. Control with LED Display ◊ Spill Proof Tempered Glass Shelves ◊ Portable Ice Cube Maker ◊ Vegetable Crisper with Humidity Control ◊ Preservation Light (not available in TFF210WNTAM or TFF210SNTAM models) -
Page 4: Safety Information
fi lled with water. • If the supply cord is damaged, it must be replaced by authorised TECO service personal, service agent or similarly qualifi ed persons in order to avoid a hazard. • Do not store fl ammable, explosive, volatile and highly corrosive materials in the refrigerator. - Page 5 • Do not splash water on the appliance. It may cause malfunction or electric shock. • Always switch off and unplug appliance before cleaning. • This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
-
Page 6: Name Of Parts And Usage
NAME OF PARTS AND USAGE TFF210WNTAM / TFF210SNTAM 1. Cabinet 12. Freezer Door 2. Freezer Air Duct 13. Freezer Door Rack 3. Freezer Glass Shelf 14. Middle Hinge 4. Freezer Vent Adjustment 15. Refrigerator Door 5. Cold Compartment 16. Refrigerator Door Dairy Rack 6. - Page 7 12. Vegetable Crisper *The Preservation Light utilizes light waves to stimulate the photosynthesis effect of fresh fruit and vegetables within the refrigerator. This assists fruit and vegetables to stay fresh for longer. NOTE: Not available in TFF210WNTAM & TFF210SNTAM models.
- Page 8 11. Vegetable Crisper *The Preservation Light utilizes light waves to stimulate the photosynthesis effect of fresh fruit and vegetables within the refrigerator. This assists fruit and vegetables to stay fresh for longer. NOTE: Not available in TFF210WNTAM & TFF210SNTAM models.
-
Page 9: Packing List
PACKING LIST Check the packing list that all items have been included. Part No. Item Portable Twist Ice 1 Piece Cube Maker Top Hinge Cover 1 Piece Warranty 1 Copy Information Sheet User’s Manual 1 Copy Note: Product specifi cations are subject to change without prior notice. -
Page 10: Transporting The Appliance & Installation
TRANSPORTING THE APPLIANCE & INSTALLATION ● The appliance must be transported only in a vertical position. The packing must be intact during the transportation. ● When unpacking and re-packing the appliance, please memorise the position of each accessory of the appliance when unpacking it. When re-packing the appliance for transportation, ensure all accessories are secured before transportation. -
Page 11: Operating Instructions
● ● ● ● WARNING... -
Page 12: Energy Saving Tips
LED DISPLAY When the refrigerator is rst powered on, for three (3) seconds the display will show all temp. indicators and then display the current temp. setting. This display will also be used to display error codes if a fault should occur (refer to Page 18). -
Page 13: Reversing The Door
REVERSING THE DOOR Follow these steps to reverse the door from the supplied position. Before proceeding, ensure the appliance is unplugged, turned off and empty of all contents. STEP 1. Top Hinge A) Locate and remove the top hinge cover, screws and hinge from the right side. - Page 14 STEP 3. Bottom Hinge A) Remove both adjustable feet by completely unscrewing them. B) Remove the screws holding the bottom hinge and remove the bottom hinge. STEP 4. A) Screw the adjustable foot into the right side. B) Fasten the bottom hinge into place on the left side. NOTE: Do not fasten completely until after the door has been correctly positioned.
-
Page 15: Maintenance
4. Interior light The refrigerator is fitted with several LED internal lights, that are not replaceable. If the lights stop working, please contact TECO Service (refer to page 21). 5. Empty the drip tray Do not attempt to remove the drip tray from the rear of the refrigerator. - Page 16 COMPARTMENT, CRISPER & RACK MAINTENANCE Please be careful when handling and removing compartment, crisper and racks. Follow the steps below to remove, clean and replace each of the refrigerator items. GLASS SHELVES & DOOR RACKS To remove glass shelves for cleaning, pull the shelf out as far as possible and then lift slightly.
-
Page 17: Disconnection Of The Appliance
DISCONNECTION OF THE APPLIANCE If a power failure occurs, even in summer, the refrigerator could store food normally for some time. 1, Power failure During a power failure, do not put additional food in the appliance and reduce opening the door frequently. Place several ice cubes into a container if power failure is anticipated beforehand, and place it in the top of the fridge. - Page 18 SYMPTOM: The refrigerator does not work effi ciently as expected. SUGGESTION: It may be caused by heavy frost, warm temperature setting, frequently opening the door or low voltage. SYMPTOM: It makes an unusual noise. SUGGESTION: It may be caused by an unbalanced appliance or unstable surface, bottles are incorrectly placed and rattling, vibration from an object on top of, behind or beside the appliance.
-
Page 19: Speci Cations
220-240 220-240 220-240 1557... - Page 20 Did you know? TECO Australia’s product range also includes: Top Load Clothes Washers Front Load Clothes Washers Twin Tub Clothes Washers Auto Sensing Condenser and Vented Clothes Dryers Refrigerators Chest and Vertical Freezers Bar Fridges ...
-
Page 21: Repairs, Service & Warranty
If you have a problem, and the problem persists after you have made the checks mentioned in this manual, contact: TECO Australia’s Service on 1300 660 037 (8:30am-4pm Mon~Fri AEST) Service Email had.service@teco.com.au Spare Parts had.parts@teco.com.au For warranty details please visit www.teco.com.au... - Page 22 HBG-V3 www.teco.com.au...
