- Page 1 USER’S MANUAL DC INVERTER FROST FREE REFRIGERATOR Models : TFF536WNMA TFF536SNMA TFF542WNTA TFF542SNTA Made By TECO Taiwan To ensure proper use of the appliance and your safety, please read the following user manual completely before use.
- Page 2 Follow the operating instructions and safety notices in this manual. If any trouble arise, do not attempt to fi x it yourself. Please contact TECO service on 1300 660 037 (refer to Page 18). This refrigerator is designed and approved for use with fl ammable R600a refrigerant.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Safety Information............. 4 - 5 Name of Parts and Usage (TFF536WNMA/TFF536SNMA) Name of Parts and Usage (TFF542WNTA/TFF542SNTA) Packing List .............. Transporting the Appliance & Installation ....Operating Instructions ..........10 - 12 Temperature Settings ..........Energy Saving Tips ..........Maintenance ......... -
Page 4: Safety Information
fi lled with water. • If the supply cord is damaged, it must be replaced by authorised TECO service personal, service agent or similarly qualifi ed persons in order to avoid a hazard. • Do not store fl ammable, explosive, volatile and highly corrosive materials in the refrigerator. - Page 5 • Do not splash water on the appliance. It may cause malfunction or electric shock. • Always switch off and unplug appliance before cleaning. • This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of perience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
-
Page 6: Name Of Parts And Usage (Tff536Wnma/Tff536Snma)
NAME OF PARTS AND USAGE Models: TFF536WNMA / TFF536SNMA 1. Freezer Section Light Switch 11. Storage Tray 2. Freezer LED Light 12. Vegetable Drawer (Approx. 8 3. Antibacterial Deodorizing Filter 13. Vegetable Crisper 4. Freezer Tempered Glass Shelf 14. Adjustable Feet 5. -
Page 7: (Tff542Wnta/Tff542Snta)
Models: TFF542WNTA / TFF542SNTA 1. Freezer Fan Switch 8. Refrigerator Section Shelves 2. Antibacterial Deodorizing Filter 9. Refrigerator LED Light 3. Freezer Section Shelf 10. Vegetable Crisper 4. Twist Ice Cube Maker 11. Adjustable Feet 5. Chill Compartment & Temp. Control 12. Freezer Door Racks 6. -
Page 8: Packing List
PACKING LIST Check the packing list that all items have been included. Part No. Item Warranty 1 Copy Information Sheet User’s Manual 1 Copy Note: Product specifi cations are subject to change without prior notice. -
Page 9: Transporting The Appliance & Installation
TRANSPORTING THE APPLIANCE & INSTALLATION ● The appliance must be transported only in a vertical position. The packing must be intact during the transportation. ● When unpacking and re-packing the appliance, please memorise the position of each accessory of the appliance when unpacking it. When re-packing the appliance for transportation, ensure all accessories are secured before transportation. -
Page 10: Operating Instructions
● ● ● ● WARNING... - Page 11 FREEZER TEMP. SETTING Press the Freezer Temp. Setting button (2) gently to cycle through the freezer temperature settings. Each gentle press of the button will be displayed as a LED indicator (1). Each gentle press of the button will adjust the temperature setting between COLD (min.) and COLDEST (max.).
-
Page 12: Energy Saving Tips
ICE MAKING To make ice cubes, fi ll the twist ice cube maker using a measuring cup (not supplied) with clean drinking water (be careful not to spill). To remove ice cubes easily, twist the tray in the ice cube maker. (If you use the twist ice maker, please be careful opening and closing the freezer door until the water has frozen completely). -
Page 13: Maintenance
MAINTENANCE The appliance should be maintained and cleaned frequently. For your safety, unplug the appliance from the mains power source before performing any maintenance. 1.Interior and exterior maintenance Clean the interior of the appliance with clean water and wipe it dry with a piece of dry cloth. - Page 14 COMPARTMENT, DRAWER & RACK MAINTENANCE Please be careful when handling and removing comparments, drawers and racks. Follow the steps below to remove, clean and replace each of the refrigerator items. CHILL ZONE It is necessary to remove the chill zone cover before removing the drawer. Pull the cover out while tilting up on the left side.
- Page 15 VEGETABLE CRISPER, DRAWERS & TRAYS To remove the vegetable crisper, gently slide the crisper out and over the stopper. The crisper can now be lifted away for cleaning. Refer to Fig. 5 below. Fig. 5...
-
Page 16: Disconnection Of The Appliance
DISCONNECTION OF THE APPLIANCE If a power failure occurs, even in summer, the refrigerator could store food normally for some time. 1, Power failure During a power failure, do not put additional food in the appliance and reduce opening the door frequently. Place several ice cubes into a container if power failure is anticipated beforehand, and place it in the top of the fridge. - Page 17 SYMPTOM: The refrigerator does not work effi ciently as expected. SUGGESTION: It may be caused by heavy frost, warm temperature setting, frequently opening the door or low voltage. SYMPTOM: It makes an unusual noise. SUGGESTION: It may be caused by an unbalanced appliance or unstable surface, bottles are incorrectly placed and rattling, vibration from an object on top of, behind or beside the appliance.
-
Page 18: Repairs, Service & Warranty
IF SERVICE IS REQUIRED: If you have a problem, and the problem persists after you have made the checks mentioned above, contact: TECO Australia’s Service on 1300 660 037 For warranty details please visit www.teco.com.au Complete and retain the following information:... -
Page 19: Specifications
SPECIFICATIONS TFF536WNMATEBF TFF542WNTATEBF Model Number TFF536SNMATEBF TFF542SNTATEBF Climate Class Classification of Group 5T Installation and Use Indoor Use Only Rated Total Chill Gross Fridge Volume (L) Freezer Drawer Rated Total Chill Storage Fridge Volume (L) Freezer Drawer Voltage 220~240 Frequency... - Page 20 Did you know? TECO Australia’s product range also includes: Top Load Clothes Washers Front Load Clothes Washers Twin Tub Clothes Washers Auto Sensing Condenser and Vented Clothes Dryers Refrigerators Chest and Vertical Freezers Bar Fridges ...
