Summary of Contents for TECO TAF230WMPCM
- Page 1 REFRIGERATOR User Manual TAF230WMPCM...
-
Page 2: Table Of Contents
CONTENTS Important Safety Instructions Installation Instructions Reversing the Door Starting Instructions Structure and Functions Maintenance and Care of the Appliance Troubleshooting Repair, Service & Warranty Specifications... -
Page 3: Important Safety Instructions
• Follow the operating instructions and safety notices in this manual. • If any trouble arise, do not attempt to fix it yourself. Please contact TECO service on 1300 660 037 (8:30am - 4pm Mon~Fri AEST). - Page 4 • Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance. • If the supply cord is damaged, it must be replaced by authorised TECO service personal, service agent or similarly qualified persons in order to avoid a hazard.
- Page 5 • This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
-
Page 6: Installation Instructions
Installation Instructions • Before using the refrigerator for the first time, remove all of the packing materials, including the foam base and adhesive tape holding accessories in place; tear off the protective film on th e doors and the refrigerator body. •... -
Page 7: Reversing The Door
Reversing the Door 1) Please power off this appliance before conduct this operation. Remove all food from door shelves. 2) Remove the upper hinge cover, fitting screws of upper hinge and the upper hinge, and remove the plastic screw hole cap from the other side. 3) Remove the door and the bottom hinge assembly and the adjustable foot, then assemble the bottom hinge assembly and the adjustable foot on the other side. -
Page 8: Starting Instructions
4) Assemble the shaft of the top hinge as in the picture below. Put the door on the bottom hinge, and assemble the upper hinge, upper hinge cover and the plastic screw hole cap successively. (The pictures above are only for reference only. The actual configuration depends on the physical product). -
Page 9: Structure And Functions
Structure and Functions Temperature control knob • If the ambient temperature is too high or in summer, according to actual needs, the thermostat can be adjusted to MAX. • If the ambient temperature is too low or in winter, according to actual needs, the thermostat can be adjusted to MIN. -
Page 10: Maintenance And Care Of The Appliance
Maintenance and Care of the Appliance • Dusts behind the refrigerator and on the ground shall be timely cleaned to improve the cooling effect and energy saving. • Check the door gasket regularly to make sure there are no debris. Clean the door gasket with a soft cloth dampened with soapy water or diluted detergent. -
Page 11: Troubleshooting
Troubleshooting Check whether the appliance is connected to power or whether the plug is in well contact . Failed operation Check whether the voltage is too low. Check whether there is a power failure or partial circuits have tripped. Odorous foods shall be tightly wrapped. Check whether there is any rotten food. -
Page 12: Repair, Service & Warranty
IF SERVICE IS REQUIRED : If you have a problem, and the problem persists after you have made the checks mentioned in this manual, contact: TECO Australia’s Service on 1300 660 037 (8:30am - 4pm Mon~Fri AEST). For warranty details please visit www.teco.com.au Service Email : had.service@teco.com.au... -
Page 13: Specifications
TAF230WMPCM 220 ~ 240 LED 2W Lamp Rated Power R600a 1420... - Page 14 Teco's warranty information for the product purchased is available at www.teco.com.au. A copy of the warranty may also be obtained by contacting Teco's Warranty and Service Department on 1300 660 037 during business hours (Mon - Fri 8.30am - 4pm AEST).
