- Page 1 Engineered To Perform USER’S MANUAL Refrigerator Model TBF134WMDB To ensure proper use of the appliance and your safety, please read the following user manual completely before operating this appliance.
- Page 2 The appliance has not been designed or manufactured for professional use. Teco declines all responsibility for damage deriving from improper use of the appliance. The refrigerator has undergone the necessary tests on the tightness of the refrigeration circuit and complies with the safety regulations for electrical appliances.
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1 - 2 Safety precautions..........Name of parts and usage........Installation instructions......... Transporting the appliance ........Operating instructions ......... Defrosting ............Maintenance ............10 - 11 Disconnection of the appliance ......12 - 13 Reversing the door ..........Troubleshooting .......... -
Page 4: Safety Precautions
R600A Iso-butane Refrigerant Hydrocarbon refrigerants have excellent refrigerant properties and minimal low global warming potential and no ozone depletion potential. WARNING This appliance contains a small quantity of fl ammable, non- synthetic R600A refrigerant: Hydrocarbon refrigerants cannot be ‘retrofi tted’ to the appliance that has not been designed and approved to use that type of refrigerant. - Page 5 Young children should be supervised to ensure that they do not play with the appliance. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualifi ed persons in order to avoid a hazard. When disposing of the appliance, do so only at an authorised waste disposal centre.
-
Page 6: Name Of Parts And Usage
NAME OF PARTS AND USAGE 1. Ice box compartment 7. Adjustable leg(s) 2. Defrost drip tray 8. Door storage 3. Lamp switch 9. Storage bar 4. Temperature control dial 10. Internal can dispenser * 5. Removable shelf 11. Can dispenser frame 6. - Page 7 PACKING LIST Part No. Model TBF134WMDB (see pg.3) Ice cube tray 1 piece User manual 1 copy Warranty 1 copy Information Note: Product specifi cations are subject to change without prior notice...
-
Page 8: Transporting The Appliance
TRANSPORTING THE APPLIANCE 1.The appliance must be transported only in a vertical position. The packing must be intact during the transportation. 2. When unpacking and re-packing the appliance, please memorise the position of each accessory of the appliance when unpacking it. When re-packing the appliance for transportation, ensure all accessories are secured before transportation. - Page 9 WARNING WARNING...
-
Page 10: Defrosting
DEFROSTING Heavy frost will effect the refrigerating process or internal temperature of the appliance and increase the power consumption. Thus, defrosting is required if the frost is >5mm thick. Defrosting is a manual process. Please follow these steps: 1. Switch off and disconnect the appliance. 2. -
Page 11: Maintenance
MAINTENANCE The appliance should be maintained and cleaned frequently. For your safety, pull the plug out of the socket before cleaning. 1.Interior and exterior maintenance Clean the interior of the appliance with clean water and wipe it dry with a piece of dry cloth. Cleansers such as soap powder, abrasive cleaning powder, alkali cleansers, chemical cloth, thinners, alcohol, acid petroleum products and hot water should not be used to clean the refrigerator as they... -
Page 12: Disconnection Of The Appliance
DISCONNECTION OF THE APPLIANCE If a power failure occurs, even in summer, the refrigerator could store food normally for some time. 1, Power failure During a power failure, do not put additional food in the appliance and reduce opening the door frequently. Place several ice cubes into a container if power failure is anticipated beforehand, and place it in the top of the fridge. -
Page 13: Reversing The Door
REVERSING THE DOOR Follow these steps to reverse the door from the supplied position. Step 1. Remove the cover from the door hinge and Step 2. Lift the door from remove the two screws holding the hinge bracket. the hinge. Place the door in a safe location to avoid scratches or damage. - Page 14 Step 6. The hinge pin must be removed Step 7. Fasten the and relocated onto the opposite side adjustable leg and frame of the bracket. Remove the nut and screw into the right side washers, relocate the pin then fasten. of the refrigerator.
-
Page 15: Troubleshooting
TROUBLESHOOTING The following cases are not malfunctions: 1. Moisture may form as condensation on the outside of the appliance during humid conditions. To remove excess moisture, wipe clean. 2. The fl ow of refrigerant through the pipeline coil could cause gurgling, simmilar to water boiling. -
Page 16: Repairs, Service & Warranty
IF SERVICE IS REQUIRED: If you have a problem, and the problem persists after you have made the checks mentioned above, contact: TECO Australia’s Service on 1300 660 037 For warranty details please visit www.teco.com.au Complete and retain the following information:... -
Page 17: Specifications
SPECIFICATIONS Model TBF134WMDB Climate class Clasifi cation of Class 1 installation and use Indoor use only Rated Fridge Total Gross Ice box Volume (L) Voltage (V) Frequency (Hz) Noise Level (dB) Refrigerant type R600A Ambient Operating temp ( Height Dimensions... - Page 18 CBF-PV...
