Instruction Manual
Customer Service:
Tel.: +1.800.873.8731
Fax: +1.847.662.4150
custserv@dynapar.com
1
SLIM Tach
SL85
®
Magnetoresistive Encoder
Designed for use in
0.625" to 3.000" (16mm to 76mm)
Shaft Diameters
1675 Delany Road * Gurnee, IL * 60031 * USA
Technical Support
Tel.: +1.800.234.8731
Fax: +1.847.782.5277
northstar.techsupport@dynapar.com
Website: www.dynapar.com
*791-1008-00 Rev.
DYNAPAR
©
European Sales Representative
Hengstler GmbH
Uhlandstrasse 49, 78554 Aldingen - Germany
www.hengstler.de
J
*
+1.800.873.8731
Advertisement
Table of Contents
Related Manuals for DYNAPAR SLIM Tach SL85
Summary of Contents for DYNAPAR SLIM Tach SL85
- Page 1 1675 Delany Road * Gurnee, IL * 60031 * USA Customer Service: Technical Support European Sales Representative Tel.: +1.800.873.8731 Tel.: +1.800.234.8731 Hengstler GmbH Fax: +1.847.662.4150 Fax: +1.847.782.5277 Uhlandstrasse 49, 78554 Aldingen - Germany custserv@dynapar.com northstar.techsupport@dynapar.com www.hengstler.de Website: www.dynapar.com *791-1008-00 Rev. DYNAPAR +1.800.873.8731 ©...
-
Page 2: Table Of Contents
Dynapar in these developments. Methods and apparatus disclosed herein may be subject to U.S. Patents existing or applied for. Dynapar reserves the right to add, improve, modify, or withdraw functions, design modifications, or products at any time without notice. -
Page 3: Introduction
Failure to comply with these precautions or with specific warnings elsewhere in this manual violates safety standards of design, manufacture, and intended use of the instrument. Dynapar assumes no liability for the customer's failure to comply with these requirements. -
Page 4: General
S85-COVER-TH Figure 1: SLIM Tach SL85 Thru-Shaft Exploded View w/ Spare Parts (Shown w/ Optional Tower) ® NOTE: If you have further questions, please call Dynapar customer service (614) 818-1150+ext. 282 or 278 with serial number ready. DYNAPAR +1.800.873.8731 ©... -
Page 5: Specifications
Minimum 18 g’s RMS, 5-2000 Hz Shock (Encoder Housing) 1 meter drop tested, min 30 g’s shock spectrum Standards EN 61326 *NOTE: Provides CE compliance in applications where cable length is less than 30 meters. Specifications subject to change without notice DYNAPAR +1.800.873.8731 ©... -
Page 6: Installation
Inspect shipping container for external damage. All claims for damage (apparent or concealed) or partial loss of shipment must be made in writing to Dynapar within (5) days from receipt of goods. If damage or loss is apparent, please notify the shipping agent immediately. -
Page 7: Encoder Frame Installation
Use a 3/8 inch hex wrench to tighten a nominal 25 foot pounds. See Figure 3. NOTE On End-of-Shaft units, one may wish to mount the encoder frame after mounting the pulse wheel. See page 10. Figure 3: Typical Motor Mounting DYNAPAR +1.800.873.8731 ©... -
Page 8: Thru-Shaft Pulse Wheel Installation
End-Of-Shaft and Thru-Shaft models. Be sure the letter “Z” and “This Side Out” are visible on the face of the pulse wheel after installation. Detail of surfaces that must be flush. Figure 4: Pulse Wheel Orientation DYNAPAR +1.800.873.8731 ©... - Page 9 NorthStar SLIM Tach SL85 Instruction Manual ® Figure 5: SLIM Tach SL85 End-of-Shaft Exploded View ® DYNAPAR +1.800.873.8731 ©...
-
Page 10: Motor Facing And Shaft For End-Of-Shaft Sl85
The magnetic properties of the pulse wheel material can also be distorted or erased by exposure to strong magnetic fields. Remove pulse wheel assembly from packaging. 2. Place one spacer washer into the shaft recess of the pulse wheel. DYNAPAR +1.800.873.8731 ©... -
Page 11: Electrical Installation
(e.g., A and A complement). *NOTE: Provides CE compliance in applications where cable length is less than 30 meters. CAUTION! Reversing power and common will not damage the unit. However, applying power to any of the sensor outputs may cause damage. DYNAPAR +1.800.873.8731 ©... -
Page 12: Quick Release Connector Hood Wiring
5. Mate connector into place on sensor mount and snap the two latches into place. If only one sensor is being installed, ensure cover plate is installed over other sensor hole. Figure 8: Sealed Industrial Latching Connector DYNAPAR +1.800.873.8731 ©... -
Page 13: Returning Equipment To Dynapar
If it is necessary to return the unit for repair or replacement, a Return Goods Authorization (RGA) number must be obtained from a factory representative before returning the equipment to our service department. When returning an instrument for service, the following information must be provided before Dynapar can attempt any repair. 1. Instrument model and serial number 2. - Page 14 1675 Delany Road * Gurnee, IL * 60031 * USA Customer Service: Technical Support European Sales Representative Tel.: +1.800.873.8731 Tel.: +1.800.234.8731 Hengstler GmbH Fax: +1.847.662.4150 Fax: +1.847.782.5277 Uhlandstrasse 49, 78554 Aldingen - Germany custserv@dynapar.com northstar.techsupport@dynapar.com www.hengstler.de Website: www.dynapar.com DYNAPAR +1.800.873.8731 ©...
