- Page 1 User Manual CVHDSDI1B HDMI to SDI Converter, with 2 SDI outputs All Rights Reserved Version: CVHDSDI1B _2017V1.1...
- Page 2 HDMI to SDI Converter MAINTENANCE Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner of benzine to clean this unit. PRODUCT SERVICE 1) Damage requiring service: The unit should be serviced by qualified service personnel if: (a)The DC power supply cord or AC adaptor has been damaged;...
- Page 3 HDMI to SDI Converter preferably in the original carton. Include a letter detailing the complaint and provide a day time phone and/or email address where you can be reached. FEATURES Convert HDMI to SD/HD/3G-SDI. Distributes 1 HDMI source to 2 SD/HD/3G-SDI output simultaneously. ...
- Page 4 HDMI to SDI Converter TABLE OF CONTENTS Specifications Package Contents Panel Descriptions Connecting and Operating Maintenance Product service Warranty SPECIFICATIONS Operating Temperature Range -5 to +35�(+23 to +95�) Operating Humidity Range 5 to 90%RH (No Condensation) 1080p (50/60/59.94/30/29.97/25/24/23.98Hz) Resolutions Support 1080i (60/59.94/50Hz), 720p (60/59.94/50Hz) SDI Standard 3G -SDI/HD-SDI/SDI...
- Page 5 HDMI to SDI Converter Output Panel Input Panel """"""""" """ """"""""" """ Indicator of SDI Output Indicator of power Input SDI/HD-SDI Output port HDMI input port Power input Connecting and Operating 1. Ensure the Converter is disconnected from power. 2. Connect source to the HDMI input and sink to SDI output . 3.
- Page 6 HDMI to SDI Converter...
- Page 7 HDMI to SDI Converter ALTIMIUM 587 Avenue Blaise Pascal 77550 MOISSY-CRAMAYEL Tél : 01.64.13.31.00 Fax: 01.60.29.62.70 Mail: contact@tesca-audio.com Web: www.altimium.com...
