- Page 1 User Manual CVSDIHD1LB SDI to HDMI Converter, with 1 x Looping SDI Output All Rights Reserved Version: CVSDIHD1LB _2017V1.1...
-
Page 2: Maintenance
SDI to HDMI Converter MAINTENANCE Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner of benzine to clean this unit. PRODUCT SERVICE 1) Damage requiring service: The unit should be serviced by qualified service personnel if: (a)The DC power supply cord or AC adaptor has been damaged;... - Page 3 SDI to HDMI Converter preferably in the original carton. Include a letter detailing the complaint and provide a day time phone and/or email address where you can be reached. FEATURES Convert SD/HD/3G-SDI to HDMI Distribute 1 SD/HD/3G-SDI to 1 HDMI plus 1 looping SDI output simultaneously ...
-
Page 4: Specifications
SDI to HDMI Converter TABLE OF CONTENTS Specifications Package Contents Panel Descriptions Connecting and Operating Maintenance Product service Warranty SPECIFICATIONS -5 to +35 (+23 to +95 ) Operating Temperature Range Operating Humidity Range 5 to 90%RH (No Condensation) 1080p@23.98/24/25/29.97/30/50/59.94/60HZ; 1080i@50/59.94/60HZ; Resolutions Formats 720P@50/59.94/60HZ;... -
Page 5: Panel Descriptions
SDI to HDMI Converter PANEL DESCRIPTIONS Input Panel Output Panel (f)Indicator of HDMI Output (g)Indicator of power Input (h)SDI input port (i)SDI output port (j)HDMI output port (k)Power input Connecting and Operating Ensure the Converter is disconnected from power. Connect source to the SDI input and sink to HDMI output and SDI output . Connect 5VDC power to the converter. - Page 6 SDI to HDMI Converter Typical Application...
- Page 7 SDI to HDMI Converter ALTIMIUM 587 Avenue Blaise Pascal 77550 MOISSY-CRAMAYEL Tél : 01.64.13.31.00 Fax: 01.60.29.62.70 Mail: contact@tesca-audio.com Web: www.altimium.com...
