- Page 1 User Manual CVSDIHD-6G 6G SDI to HDMI Converter All Rights Reserved Version: CVSDIHD-6G_2018V1.1...
- Page 2 Any changes or modifications not expressly approved by the manufacture would void the user’s authority to operate the equipment. Altimium www.altimium.com...
- Page 3 Unplug the power cord when left unused for a long period of time. Information on disposal for scrapped devices: do not burn or mix with general household waste, and please treat them as normal electrical wastes. Altimium www.altimium.com...
-
Page 4: Table Of Contents
6G SDI to HDMI Converter Contents 1. Introduction ......................... 1 1.1 Introduction to CVSDIHD-6G ................1 1.2 Features ......................1 1.3 Package List ...................... 1 2. Specification ....................... 2 3. Panel Description ......................3 3.1 Front Panel ......................3 3.2 Rear Panel ......................4 3.3 Side Panel ...................... -
Page 5: Introduction
Features an 8-pin DIP switch on side panel for buttons locking or unlocking and audio input switching. Supports firmware update. 1.3 Package List 1x CVSDIHD-6G 6G SDI to HDMI Converter 1x AC power adapter (12V DC, 1A) 4x Plastic feet ... -
Page 6: Specification
Operation Temperature -25~ +70℃ Storage Temperature Relative Humility 10%-90% Maximum Power Consumption 11 watts Input Power 12V DC 1A AC Adapter Input Power 100 ~ 240V AC, 50/60 Hz Dimensions (W*H*D) 120mm x 30mm x 100mm Net Weight 317g Altimium www.altimium.com... -
Page 7: Panel Description
⑥ SDI SOURCE LED: Illuminates blue when the input signal comes from SDI IN 1 port. Blinks blue when the input signal comes from SDI IN 2 port. ⑦ FW: Micro USB port for firmware update. Altimium www.altimium.com... -
Page 8: Rear Panel
When in the lower (1) position, the switch represents “ON”, while putting the switch in the upper (0) position represents “OFF”. Note: The DIP switches status and its corresponding setting can find at the chapter of 5.Switches Operation. Altimium www.altimium.com... -
Page 9: Top Panel
Right channel analog audio is selected. Left and right channel stereo analog audio is selected. ② VOLUME: Press the up or down direction button to increase or decrease the selected output audio. ③ MUTE: Press the button to mute or unmute all audio. Altimium www.altimium.com... -
Page 10: System Connection
All of the power switches, plugs, sockets, and power cords should be insulated and safe. All devices should be connected before power on. 4.2 System Diagram SDI: HDMI: Audio: DC 12V SDI IN 1 SDI IN 2 SDI OUT Amplifier Camera Camera SDI Display HDMI Display Altimium www.altimium.com... -
Page 11: Switches Operation
Switch 2, 3, 4 - SDI AUDIO DE-EMBED BIT 1, BIT 2, BIT 3 Switches 2, 3 and 4 are grouped together to provide 8 different ON/OFF combinations which allows eight independent pair of audio channels to be de-embedded from SDI input to HDMI, analog or AES/EBU audio output. Altimium www.altimium.com... - Page 12 The switches status and its corresponding SDI audio selection are shown in the following table: Audio Switch 2 Switch 3 Switch 4 Switch Diagram Channels 1 and 2 3 and 4 5 and 6 7 and 8 9 and 10 11 and 12 13 and 14 15 and 16 Altimium www.altimium.com...
-
Page 13: Panel Drawing
6G SDI to HDMI Converter 6. Panel Drawing DC 12V SDI IN 1 SDI OUT SDI IN 2 120 mm AES/EBU VOLUME AUDIO MUTE 6G SDI to HDMI Converter ANALOG or AES/EBU R - ANALOG HDMI OUT Altimium www.altimium.com... -
Page 14: Troubleshooting & Maintenance
Fail connection of power Make sure the power cord respond to any cord. connection is good. operation. Note: If your problem still remaining after following the above troubleshooting steps, please contact your local dealer or distributor for further assistance. Altimium www.altimium.com... -
Page 15: Customer Service
Remarks: For further assistance or solutions, please contact your local distributor. Altimium www.altimium.com... - Page 16 ALTIMIUM 587 Avenue Blaise Pascal 77550 MOISSY-CRAMAYEL Tél : 01.64.13.31.00 Fax: 01.60.29.62.70 Mail: contact@tesca-audio.com Web: www.altimium.com...
