- Page 1 User Manual SP2H2A-H2 HDMI 2.0 1x2 Splitter with Audio Breakout All Rights Reserved Version: SP2H2A-H2_2018V1.0...
- Page 2 Any changes or modifications not expressly approved by the manufacture would void the user’s authority to operate the equipment. Altimium www.altimium.com...
- Page 3 Unplug the power cord when left unused for a long period of time. Information on disposal for scrapped devices: do not burn or mix with general household waste, please treat them as normal electrical wastes. Altimium www.altimium.com...
-
Page 4: Table Of Contents
HDMI 2.0 1x2 Splitter with Audio Breakout Contents 1. Product Introduction ....................1 1.1 Features ......................1 1.2 Packing List ....................... 2 2. Specification ....................... 3 3. Panel Description ......................4 3.1 Front Panel ......................4 3.2 Rear Panel ......................4 4. -
Page 5: Product Introduction
HDMI 2.0 1x2 Splitter with Audio Breakout 1. Product Introduction Thanks for purchasing this one input to two output HDMI2.0 Splitter. The splitter supports HDMI video resolution up to 4K@60Hz 4:4:4, 1080P 3D and multichannel audio formats. In addition to passing EDID information from the display, there are multiple built-in EDID settings to simplify the installation. -
Page 6: Packing List
HDMI 2.0 1x2 Splitter with Audio Breakout 1.2 Packing List 1x HDMI 2.0 1x2 Splitter 2x Mounting Ears with 4 Screws 4x Plastic Cushions 1x 3-pin Euroblock/phoenix Connector 1x Power Adapter (5V DC 2A) 1x User Manual ... -
Page 7: Specification
HDMI 2.0 1x2 Splitter with Audio Breakout 2. Specification Video Input Input (1) HDMI Input Connector (1) Female type A HDMI HDMI Input Resolution Up to 4Kx2K@60Hz 4:4:4 HDMI Standard HDCP Version Video Output Output (2) HDMI Output Connector (2) Female type A HDMI HDMI Output Resolution Up to 4Kx2K@60Hz 4:4:4 HDMI Standard... -
Page 8: Panel Description
HDMI 2.0 1x2 Splitter with Audio Breakout 3. Panel Description 3.1 Front Panel OUT 1 OUT 2 ① Power LED: The LED illuminates green when power is applied. ② INPUT LED: The LED illuminates green when there is an input signal present. ③... -
Page 9: System Connection
HDMI 2.0 1x2 Splitter with Audio Breakout 4. System Connection 4.1 Usage Precautions Verify all components and accessories included before installation. Make sure all components and accessories included before installation. System should be installed in a clean environment with proper temperature and ... -
Page 10: Edid Management
HDMI 2.0 1x2 Splitter with Audio Breakout 5. EDID Management The Extended Display Identification Data (EDID) is used by the source device to match its video resolution with the connected display. Predefined EDID settings The 4-pin DIP switch on the rear panel can be used to set the EDID to a fixed value. Use the following table to determine the settings for the 4-pin DIP switch for specific video resolution and audio capabilities. -
Page 11: Firmware Upgrade
HDMI 2.0 1x2 Splitter with Audio Breakout EDID data transfer Please follow the procedure as below to allow the source device to obtain its EDID data from the display which is connected to the OUT 1 port: 1) Set the 4-pin DIP switch to status “1110”. 2) Connect the source device to IN port, and connect the display to the OUT 1 port. -
Page 12: Panel Drawing
HDMI 2.0 1x2 Splitter with Audio Breakout 7. Panel Drawing 170.00 mm OUT 1 OUT 2 HDMI 2.0 1x2 Splitter with Audio Breakout OUT 1 OUT 2... -
Page 13: Troubleshooting & Maintenance
HDMI 2.0 1x2 Splitter with Audio Breakout 8. Troubleshooting & Maintenance Problems Potential Causes Solutions The connecting cables may Check whether the cables not be connected correctly are connected correctly and Colour losing or no video or it may be broken. in working condition. -
Page 14: Customer Service
HDMI 2.0 1x2 Splitter with Audio Breakout 9. Customer Service The return of a product to our Customer Service implies the full agreement of the terms and conditions hereinafter. There terms and conditions may be changed without prior notice. 1) Warranty The limited warranty period of the product is fixed 3 (three) years. - Page 15 ALTIMIUM 587 Avenue Blaise Pascal 77550 MOISSY-CRAMAYEL Tél : 01.64.13.31.00 Fax: 01.60.29.62.70 Mail: contact@tesca-audio.com Web: www.altimium.com...
