Summary of Contents for CDA PC900
- Page 1 Style Fridge Freezer Installation, Use and Maintenance Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu W : www.cda.eu www.cda.eu...
- Page 2 Appliance information: Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in the event of a fault with your appliance and to register your appliance for guarantee purposes. Appliance Model...
- Page 3 Disposing of a household appliance separately avoids possible negative consequences for the environment and health deriving from inappropriate disposal and enables the constituent materials to be recovered to obtain significant savings in energy and resources. As a reminder of the need to dispose of household appliances separately, the product is marked with a crossed-out wheeled dustbin Before first use of the fridge/freezer You must allow the fridge to settle for at least twenty four hours...
- Page 4 Important This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
- Page 5 This appliance is not intended for use at altitudes exceeding 2000 metres. If one or more of your appliance’s LED lights fails, please contact CDA Customer Care to arrange a service visit. This appliance must only be serviced by CDA authorised personnel. Contact details for CDA Customer Care are on the back of this manual.
- Page 6 Fridge use • Never put liquids in the refrigerator uncovered. • Never put hot foods in the refrigerator. Warm food should be allowed to cool to room temperature before being put into the refrigerator. • Nothing should rest against the rear wall of the refrigerator, as this will cause frost and possible condensation problems which will be difficult to remove.
- Page 7 • Follow the instructions on the food packaging for storage of frozen food. If no information is provided, foods should not be stored for more than three months after the purchase date. • Store food in small packages (ideally less than 2.5kg). This reduces the freezing time and improves the quality of the food after thawing.
- Page 8 Storage Fig. 1 A - Fridge compartment 5 - Dairy shelves B - Freezer compartments 6 - Door shelves B1 - Zone 1 7 - Egg trays B2 - Zone 2 8 - Bottle shelves 1 - Fridge shelves 9 - Led lights 2 - Chiller compartment 10 - Ice trays 3 - Crisper drawers...
- Page 9 Food types and where to store them within the fridge section: Vegetables and fruits - Crisper drawers (3) Red meat - Lower fridge shelves and chiller compartment (2) White meat and fish - Lower fridge shelves and chiller compartment (2) Cheese - Dairy shelves (5) Butter and margarine - Dairy shelves (5) Bottled milk products and yoghurt - Bottle shelves (8)
-
Page 10: Control Panel
Control panel Fig. 3 1 - Fridge compartment temperature indicator 2 - Left freezer compartment temperature indicator 3 - Right freezer compartment temperature indicator 4 - Super cool indicator 5 - Super freeze indicator 6 - Quick-drink timer 7 - Quick-drink indicator 14 - Alarm indicator 8 - Eco mode indicator 15 - Screen saver sensor... - Page 11 IMPORTANT - CONTROL PANEL PROTECTION: There is a protection on the control panel which prevents an accidental touch changing the mode or function of the appliance. Before attempting to adjust the temperature or function of your appliance, it will be necessary to deactivate the display protection by pressing any sensor briefly.
- Page 12 panel protection is deactivated. • Touch the “Zone 1 sensor” (20) as many times as necessary to achieve the desired temperature. This may be set between -16°C and -24°C (not including SF) and each touch will alter the temperature by an increment of 1°C. The optimum temperature for the freezer to be set to is -18°C.
-
Page 13: Holiday Mode
temperature by an increment of 1°C. The optimum temperature for the freezer to be set to is -18°C. • Leave the display for around three seconds to stop flashing and the temperature is set. The appliance will then work towards reaching this temperature. - Page 14 Eco running mode This appliance is equipped with an ecological function which ensures that food is kept at a safe temperature and costs are kept to a minimum. To switch the eco mode on • If necessary, touch the mode sensor (17) once so that the control panel protection is deactivated.
- Page 15 • Touch and hold both the mode sensor (17) and the screen saver sensor (15) for approximately three seconds. The eco light mode indicator (10) should illuminate and the internal lights will no longer come on when the doors are opened. To switch the eco light mode off •...
- Page 16 If they feel cold enough, please remove them from the appliance immediately. If bottles are left within the freezer, particularly when carbonated, they may explode. The CDA Group cannot be held responsible for any loss or damages incurred from...
-
Page 17: Super Freeze Function
Super freeze function The super freeze function can be used to freeze large quantities of fresh food as quickly as possible. It can be used on Zone 1 and 2 independently or at the same time. For best results, switch the function on an hour prior to introducing large quantities of food to be frozen. -
Page 18: Super Cool Function
Super cool function The super cool function can be used to maintain the fridge temperature when large quantities of fresh food are introduced into the fridge. This function will deactivate automatically after 4-6 hours of continued use or once the fridge temperature sensor senses that a sufficient temperature has been reached. -
Page 19: Door Open Alarm
To switch the safety key lock on • If necessary, touch the “Fridge sensor” (18) once so that the control panel protection is deactivated. • Touch and hold both the ‘Fridge sensor’ (18) and the ‘Zone 2 sensor’ (16) for approximately three seconds. The Safety key lock indicator (11) should illuminate. -
Page 20: Care, Cleaning And Maintenance
The doors should be left slightly open to prevent the formation of mildew or odours. Please note: If one or more of your appliance’s LED lights fails, please contact CDA Customer Care to arrange a service visit. This appliance must only be serviced by CDA authorised personnel. -
Page 21: Troubleshooting
Troubleshooting If you have any problems with your appliance, you should check the troubleshooting prior to calling CDA Customer Care, to prevent unnecessary service calls and potential cost. Contact details for CDA Customer Care are on the rear cover of this manual. - Page 22 • The appliance may make what seem to be peculiar noises, even when the compressor is not running. Details of the sorts of noise you may hear are below: Cracking noise, similar to ice cracking - Normal noise that can occur when the appliance is cooling or warming.
- Page 23 Do not place fresh food in the freezer until this symbol disappears. If it does not, contact CDA Customer Care. This symbol will appear if the fridge compartment is not cold enough.
-
Page 24: Installation And Ventilation
Installation and ventilation This appliance must never be (800mm with door handles) installed close to heat sources i.e. heating elements and cookers or in damp places. 1850 Failure to provide adequate ventilation can lead to increased running costs and premature failure; it may also invalidate the warranty provided with the product. - Page 25 • Locate the appliance in a well ventilated position, away from heat sources, damp and direct sunlight. • Ensure that there is a gap of no less than 10cm above and to the sides of the appliance to allow for ventilation. The clearance between the sides and adjacent furniture must also allow the doors to open fully.
-
Page 26: Electrical Information
Electrical information Warning! This appliance must be earthed. Fig. 6 The mains lead of this appliance has been fitted with a BS 1363A 13A fused plug. To change a fuse in this type of plug, follow the steps below: 1. Remove the fuse cover and fuse. 2. - Page 27 Do not shorten the supply cable, the appliance may require removing for servicing. N.B. Ensure that the plug socket is situated in an easily accessible place. If the power supply cable is damaged, it must be replaced by a CDA authorised agent.
- Page 28 Notes:...
- Page 29 Notes:...
- Page 30 Notes:...
- Page 31 Storage volume (freezer) Star rating °C Defrosting type Automatic Climate class Airborne accoustic noise emissions dB(A) E & O E. All instructions, dimensions and illustrations are provided for guidance only. CDA reserve the right to change specifications without prior notice.
- Page 32 Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu W : www.cda.eu T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu W : www.cda.eu www.cda.eu...
