AlleyOOP Sports 14ft VariableBounce Trampoline System User Manual page 19

Assembly and Installation Instructions
Pole 4
8 net meshes from strap buckle
Pole 5 Pole 3
Pole 2
Doorway of trampoline
No gap between cap and
foam/sleeve
Pole 1
Pole 1
View from inside trampoline looking outward
22)
Ensure the warning placard is correctly positioned: Refer to the photos in Step
#21 for confirmation.
On the end of the net with the warning label, locate the buckle at the top of the net,
and count 8 meshes away from the strap buckle at the end of the net. Your net may
have a red thread sewn into the top strap at this location; you may use this as a refer-
ence instead of counting. Keep in mind, this number is approximate, and the net
may need to be adjusted so that the doorway is centered between poles 8 and 1.
Hang the top of the net from the ball end cap, beginning at the enclosure pole to the
right of the doorway (Pole 1). Continue to hang the top strap of the net from the en-
closure poles in a counter-clockwise direction. The top strap will not be perfectly
straight between poles.
A
B
23)
Continue hanging the net around the circumference, back to pole 1. Thread the loose end of the net strap through
the inner slot in the buckle, then over the center divider, and back out through the outer slot as shown in photos A and B
above to join the two sides of the net. The strap should exit the buckle behind the buckle tab as shown in photo B above.
Tighten the top and bottom straps most of the way, but leave the net slightly loose.
Note: Bottom of net may not be touching trampoline at this time. This is normal.
19
