Assembly and Installation Instructions
14)
Lay the 8 frame pad sections on the trampoline to create a full circle around the trampoline frame. Align pad so that small flaps
on outside edge of pad skirt line up over each leg of trampoline.
Pad connector
Ref. #7b
15)
Two pad connectors are used to connect adjacent pad sections together; one pad connector connects to the top of each pad section
and the second pad connector connects to the bottom of each pad section.
Frame pad section
Ref. #7a
Small flaps in
pad skirt
WARNING: Trampoline use is not recommended without the frame
pad installed. The frame pad is designed to reduce the possibility of
injury by protecting the user from coming into contact with the frame
and springs of the trampoline. It is very important that you properly and
securely attach the frame pad to the frame, and that it is in the correct posi-
tion prior to using the trampoline.
Pad connector
15
Pad connector
