AlleyOOP Sports 14ft VariableBounce Trampoline System User Manual page 13

Assembly and Installation Instructions
Warning label on
mat facing up
(Top view)
9)
Connect jumping mat to trampoline frame using 4 springs.
Connect each spring to a V-ring and spring notch, approximately
1/4 circle apart from each other. Warning labels must face up.
Note: For this step, the springs do not have to be perfectly
spaced. They are to help keep tension on the mat temporarily
while you attach the remaining springs.
Spring
Ref. #6
Spring notches
(Top view)
10)
Start at a spring that is already connected. While standing
outside the frame, count 4 V-rings and spring notches clockwise,
and connect another spring. The easiest way to connect a spring is
to hook spring onto V-ring, then pull it toward you and hook it
into spring notch on top of frame rail.
Mat
Ref. #5
Spring
Ref. #6
Warning label on
mat facing up
V-rings
Spring
Ref. #6
TIP: For easy spring installation, connect spring to V-ring of mat
and pull toward you, to connect to frame. Use a second spring as
a tool to hook onto the one you are installing.
IMPORTANT: If you have a PowerBounce Trampoline, open the
separate PowerBounce box and use those instructions to install
the PowerBounce springs while you install the standard springs
in the following steps.
11)
Continue counting 4 V-rings and notches and connecting a
spring until you have gone all the way around the trampoline.
When you get to a spring that you connected in Step 9, reposition
it if necessary, so that the springs are all spaced exactly 4 V-rings
and spring notches apart.
13
(Top view)
