Assembly and Installation Instructions
If your horizontal legs have snap buttons, continue reading. If not, skip to the next step.
Hole in leg socket
of trampoline rail.
All holes shown
correctly lined up with
each other.
Hole in vertical leg
piece, shown with
indentation facing out.
Snap button
(Top view showing whole
trampoline frame assembled.)
Correct
Holes in leg assembly point toward
Incorrect
center of trampoline
(rotate horizontal legs
180 degrees)
Leg assembly
Leg assembly
IMPORTANT: As you connect leg assemblies to rails, pay careful attention to holes in vertical leg pieces. All holes are designed to face center of
trampoline and be aligned with holes in leg sockets of trampoline, when properly installed.
If holes in vertical legs are not facing toward middle of trampoline, you will have to flip the whole leg assembly around 180 degrees.
Be sure vertical leg pieces have indented side facing away from trampoline .
11
