STEP 4
4.1 Attach Panel(A)to assembled unit and tighten Cam-Lock Nut(3)using screwdriver.
4.2 Cover Cam-Lock with Round Sticker(6).
4.3 Unfold Bin(7)and slide into the storage.
Recommended Maximum Weight
15
15
*Unit in Pound(lbs)
WARNING:
>This unit has been designed to support the
maximum loads shown. Exceeding these
load limits could cause sagging, instability,
product collapse, and/or serious injury.
>DO NOT allow children to climb on unit.
>Put heavier items on lower shelves.
its Space. its Budget
Approx. 30 minutes
Approx. 20 minutes
Approx. 15 minutes
Approx. 10 minutes
Approx. 5 minutes
Recomm. 2 Person
Recomm. 1 Person
No Tools Required
Tool Required
Tool Required
Customer Service
Tel/Fax: 281.500.9372
Toll Free: 773.299.8111 (Mon - Fri 9am - 5pm)
Email: support@furinno.com
www.furinno.com
Assembly Instruction
Furinno Simplistic 2-Tier Organizer
with Bin Drawers
13233
MODEL
:
DIMENSION :
22.4"(W) x 24.3"(H) x 11.2"(D)
1323320140717
