STEP 4
Attach Panel(E) to the back position
of the unit with Power Pin(4).
STEP 5
Unfold Bin(5)and slide into the storage.
Recommended Maximum Weight
25
15
15
15
15
25
*Unit in Pound(lbs)
WARNING:
>This unit has been designed to support the
maximum loads shown. Exceeding these
load limits could cause sagging, instability,
product collapse, and/or serious injury.
>DO NOT allow children to climb on unit.
>Put heavier items on lower shelves.
its Space. its Budget
Approx. 30 minutes
Approx. 20 minutes
Approx. 15 minutes
Approx. 10 minutes
Approx. 5 minutes
Recomm. 2 Person
Recomm. 1 Person
No Tools Required
Tool Required
Tool Required
Customer Service
Tel/Fax: 281.500.9372
Toll Free: 773.299.8111 (Mon - Fri 9am - 5pm)
Email: support@furinno.com
www.furinno.com
Assembly Instruction
Furinno Simplistic 9-Cube Organizer
with Bins
13207
MODEL
:
DIMENSION :
26.4"(W) x 26.6"(H) x 7.7"(D)
1320720140716
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Furinno 13207
Summary of Contents for Furinno 13207
- Page 1 STEP 4 Attach Panel(E) to the back position of the unit with Power Pin(4). its Space. its Budget Assembly Instruction Furinno Simplistic 9-Cube Organizer with Bins 13207 MODEL DIMENSION : 26.4”(W) x 26.6”(H) x 7.7”(D) Approx. 10 minutes Approx. 15 minutes Approx.
- Page 2 STEP 1 Hardware List Parts List Attach Panel(B)to Panel(D)with Dowel(3), as shown: Top/Bottom Panel M4x32mm Screw 2pcs 16pcs Shelf Panel 2pcs M6x20mm Dowel 8pcs M6x40mm Dowel Side Panel 2pcs 8pcs Power Pin Center Panel 32pcs 6pcs Non-Wooven Bin 3pcs Back Panel 4pcs STEP 2 Attach Panel(A)to assembled unit with Dowel(2), as shown:...
