STEP 5
Attach Panel (C&D) to Panel (B&G) using
Screw (1), as shown.
STEP 7
Attach Panel (H&I) to the back of the storage
with Power Pin (7).
Recommended Maximum Weight
15
*Unit in Pound(lbs)
STEP 6
Attach Panel (A) to assembled unit and tighten
Mini Fix Cam (5) using screwdriver.
STEP 8
Unfold Bin (9&10) and slide into the storage.
WARNING:
>This unit has been designed to support the
maximum loads shown. Exceeding these
load limits could cause sagging, instability,
product collapse, and/or serious injury.
>DO NOT allow children to climb on unit.
>Put heavier items on lower shelves.
its Space. its Budget
Approx. 20 minutes
Recomm. 1 Person
Tool Required
Tool Required
Customer Service
Tel/Fax: 281.500.9372
Toll Free: 773.299.8111 (Mon - Fri 9am - 5pm)
Email: support@furinno.com
www.furinno.com
Assembly Instruction
Furinno Econ Hallway Console Table
with 4-Foldable Bins
13122
MODEL
:
DIMENSION :
23.6"(W) x 31.5"(H) x 9.1"(D)
1312220150701
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Furinno 13122
Summary of Contents for Furinno 13122
- Page 1 Attach Panel (A) to assembled unit and tighten Screw (1), as shown. Mini Fix Cam (5) using screwdriver. its Space. its Budget Assembly Instruction Furinno Econ Hallway Console Table with 4-Foldable Bins 13122 MODEL DIMENSION : 23.6”(W) x 31.5”(H) x 9.1”(D) Approx.
- Page 2 STEP 1 Hardware List Parts List 1.1 Install Dowel (3) and Nail Leg (8) into Panel (C&D). 1.2 Insert Mini Fix Cam (5) into the pre-drilled holes on Panel (C&D). Top Panel Screw M3.5x32mm 1pcs 22pcs 1.3 Tighten Mini Fix Bolt (4) on Panel (A). Bottom Panel Screw M3.5x10mm 4pcs...
