STEP 5
Attach Panel(D)&(E)to assembled unit.Tighten Cam-Lock Nut(3) using screwdriver.
STEP 6
Attach Panel(G)to the back
of the unit using Power Pin(5).
Recommended Maximum Weight
15
10
6
10
10
*Unit in Pound(lbs)
WARNING:
>This unit has been designed to support the
maximum loads shown. Exceeding these
load limits could cause sagging, instability,
product collapse, and/or serious injury.
>DO NOT allow children to climb on unit.
>Put heavier items on lower shelves.
its Space. its Budget
Approx. 30 minutes
Recomm. 2 Person
Tool Required
Tool Required
Customer Service
Tel/Fax: 281.500.9372
Toll Free: 773.299.8111 (Mon - Fri 9am - 5pm)
Email: support@furinno.com
www.furinno.com
Assembly Instruction
Furinno Econ 6-Cube Organizer
13093
MODEL
:
DIMENSION :
35.1"(W) x 23.6"(H) x 9.4"(D)
1309320140530
