  • Page 1 W1050/W1050S/HT1070A Digital Projector User Manual V1.20...

  • Page 2: Table Of Contents

    Table of contents Important safety Maintenance ....58 instructions ....3 Care of the projector ......58 Lamp information........59 Introduction....7 Troubleshooting..66 Projector features ........7 Specifications....67 Shipping contents........8 Projector exterior view ......10 Dimensions ..........68 Positioning your Ceiling mount installation......68 projector .....

  • Page 3: Important Safety Instructions

    Important safety instructions Your projector is designed and tested to meet the latest standards for safety of information technology equipment. However, to ensure safe use of this product, it is important that you follow the instructions mentioned in this manual and marked on the product.
  • Page 4 Safety Instructions (Continued) The lamp becomes extremely hot 10. Do not place this product on an during operation. Allow the unstable cart, stand, or table. The projector to cool for product may fall, sustaining approximately 45 minutes prior serious damage. to removing the lamp assembly for replacement.
  • Page 5 Safety Instructions (Continued) 13. Do not place this projector in any of 14. Do not block the ventilation holes. the following environments. - Do not place this projector on a blanket, bedding or any other soft - Space that is poorly ventilated or surface.
  • Page 6 BenQ to have the projector serviced. 17. Do not step on the projector or place any objects upon it. Besides...

  • Page 7: Introduction

    Introduction Projector features This model is one of the best projectors available in the world. You can enjoy the best performance video quality with up to 300-inch projection across various devices such as PC, laptop, DVD and VCR even document camera to bring all possibility to life. The projector offers the following features •...

  • Page 8: Shipping Contents

    Shipping contents Carefully unpack and verify that you have all of the items shown below. If any of these items are missing, please contact your place of purchase. Standard accessories The supplied accessories will be suitable for your region, and may differ from those illustrated.
  • Page 9 Optional accessories Spare lamp kit Carry bag Ceiling mount kit 3D glasses Introduction 9...

  • Page 10: Projector Exterior View

    Projector exterior view External control panel Front/upper side (See "Projector" on page 11 details.) Lamp cover Vent (air inhale) Focus ring Zoom ring Front IR remote sensor Projection lens Quick-release lever USB mini-B input jack 10. RS-232 control port 11. RGB (PC) signal input jack 12.
  • Page 11 Controls and functions Projector TEMP (temperature) warning light Lights up red if the projector's temperature becomes too high. See "Indicators" on page 65 for details. LAMP indicator light Indicates the status of the lamp. Lights up or flashes when the lamp has developed a problem.
  • Page 12 BenQ projector ceiling mount kit and that you ensure it is securely and safely installed. If you use a non-BenQ brand projector ceiling mount kit, there is a safety risk that the projector may fall from the ceiling due to an improper attachment through the use of the wrong gauge or length screws.
  • Page 13 Remote control BRIGHT BOOST BRIGHT BOOST is not supported by this model. Activates the 3D On-Screen Display (OSD) menu item. BRIGHT Displays Bright mode menu. COLOR TEMP Displays the color temperature setting bar. 10. GAMMA Selects a gamma value. Turns off the projector. See "Shutting down the projector"...
  • Page 14 18. CONTRAST 21. COLOR MANAGE Displays the contrast setting bar. Displays the color management setting 19. AUTO bar. 22. ECO BLANK Automatically determines the best picture timings for the displayed Press the ECO BLANK button to turn image. See "Auto-adjusting the image" off the image for a period of time with on page 23 for details.
  • Page 15 Replacing the remote control battery To open the battery cover, turn the remote control over to view its back, push on the finger grip on the cover and slide it up in the direction of the arrow as illustrated. The cover will slide off. Remove any existing batteries (if necessary) and install two AAA batteries observing the battery polarities as indicated in the base of the battery compartment.

  • Page 16: Positioning Your Projector

    Select this location with the projector suspended upside-down from the ceiling behind the screen. Note that a special rear projection screen and the BenQ Projector Ceiling Mounting Kit are required for this installation location. Set Rear Ceiling in the Projector Position* menu after you turn the projector on.

  • Page 17: Obtaining A Preferred Projected Image Size

    (about 4.0 m) screen is required. All measurements are approximate and may vary from the actual sizes. BenQ recommends that if you intend to permanently install the projector, you should physically test the projection size and distance using the actual projector in situ before you permanently install it, so as to make allowance for this projector's optical characteristics.

  • Page 18: Connection

    Connection When connecting a signal source to the projector, be sure to: Turn all equipment off before making any connections. Use the correct signal cables for each source. Ensure the cables are firmly inserted. VGA cable VGA to DVI-A cable USB Cable HDMI cable Video cable...

  • Page 19: Connecting A Computer

    • In the connections shown above, some cables may not be included with the projector (see "Shipping contents" on page 8). They are commercially available from electronics stores. • For detailed connection methods, see pages 19-21. • For the combination of an active audio in source, see the marks in the illustration.

  • Page 20: Connecting Video Source Devices

    Connecting Video source devices You need only connect the projector to a Video source device using just one of the above connecting methods, however each provides a different level of video quality. The method you choose will most likely depend upon the availability of matching terminals on both the projector and the Video source device as described below: Terminal Terminal...
  • Page 21 Connecting a composite source device Examine your Video source device to determine if it has an unused composite output jack available: • If so, you can continue with this procedure. • If not, you will need to reassess which method you can use to connect to the device.

  • Page 22: Operation

    Operation Starting up the projector Plug the power cord into the projector and into a power outlet. Turn on the power outlet switch (where fitted). Check that the POWER indicator light on the projector lights orange after power has been applied. •...

  • Page 23: Adjusting The Projected Image

    • If no signal is detected for 3 minutes, the projector automatically enters ECO BLANK mode. Adjusting the projected image Adjusting the projection angle The projector is equipped with 1 front adjuster foot and 2 rear adjuster feet. These adjusters change the image height and projection angle. To adjust the projector: Pull the quick-release lever and lift the front of the projector.
  • Page 24 Fine-tuning the image size and clarity Adjust the projected image to the size that you need using the zoom ring. Then sharpen the image by rotating the focus ring. Correcting keystone Keystoning refers to the situation where the projected image is noticeably wider at either the top or bottom.

  • Page 25: Using The Menus

    Using the menus The projector is equipped with On-Screen Display (OSD) menus for making various adjusents and settings. There are two menu types for your selection. One is Basic, and the other is Advanced. Below is the overview of the Basic menu -- without input signal. Highlight Menu item The following example describes how to set the OSD menu in the Basic menu.
  • Page 26 Below is the overview of the Basic menu -- with input signal. Highlight Menu item The following example describes how to set the OSD menu in the Basic menu. Press MENU to turn the OSD menu on. to select the desired item and follow the on-screen instructions to select your settings.
  • Page 27 Below is the overview of the Advanced menu. Main menu icon Main menu Highlight (selected) Status Sub-menu Press MENU to the previous page or to exit. Current input signal The following example describes how to set the OSD menu. Press MENU to turn the OSD menu Press to select Background Color and...

  • Page 28: Securing The Projector

    Securing the projector Using a security cable lock The projector has to be installed in a safe place to prevent theft. Otherwise, purchase a lock, such as the Kensington lock, to secure the projector. You can locate a Kensington lock slot on the rear side of the projector. See item 20 on page details.
  • Page 29 Write down the number and turn off your projector. Seek help from the local BenQ service center to decode the number. You may be required to provide proof of purchase documentation to verify that you are an authorized user of the projector.

  • Page 30: Switching Input Signal

    Keep this manual in a safe place. Confirm the new password by re-entering the new password. You have successfully assigned a new password to the projector. Remember to enter the new password next time the projector is started. To leave the OSD menu, press on the projector or remote control.

  • Page 31: Selecting The Aspect Ratio

    Press until your desired signal is selected and press OK on the projector or remote control. Once detected, the selected source information will display on the screen for seconds. If there is multiple equipment connected to the projector, repeat steps 1-2 to search for another signal. •...
  • Page 32 About the aspect ratio In the pictures below, the black portions are inactive areas and the white portions are active areas. OSD menus can be displayed on those unused black areas. Auto: Scales an image proportionally to fit the projector's native resolution in its horizontal or vertical width.

  • Page 33: Optimizing The Image

    Optimizing the image Selecting a picture mode The projector is preset with several predefined picture modes so that you can choose one to suit your operating environment and input signal picture type. To select an operation mode that suits your need, you can follow one of the following steps.
  • Page 34 Renaming user modes You can change User 1 and User 2 to the names easy to be identified or understood by the users of this projector. The new name can be up to 12 characters including English letters (A-Z, a-z), digits (0-9), and space (_). To rename user modes: Make sure the Menu Type is Advanced.
  • Page 35 Fine-tuning the image quality According to the detected signal type, there are some user-definable functions available when User 1 or User 2 mode is selected. Based on your needs, you can make adjustments to these functions by selecting them and pressing on the projector or remote control.

  • Page 36: Advanced Picture Quality Controls

    Advanced picture quality controls There are more advanced functions in the Advanced menu > Picture > Advanced... menu to be adjusted to your preference. To save the settings, just press MENU to leave the OSD menu. Setting Black Level Select Black Level and press on the projector or remote control to select 0 IRE or 7.5 IRE.
  • Page 37 Setting a preferred color temperature Select Color Temperature Fine Tuning in the Advanced menu > Picture > menu and press OK on the projector or remote control. Advanced... Select Color Temperature and select Cool, Normal, Lamp Native or Warm by pressing on the projector or remote control.
  • Page 38 Press to select Hue and press to select its range. Increase in the range will include colors consisted of more Yellow GREEN proportions of its two adjacent colors. Please refer to the illustration to the right for how the colors relate to each other. For example, if you select Red and set its Cyan Magenta...

  • Page 39: Hiding The Image

    Hiding the image Press the ECO BLANK button from remote control to turn off the image for a period of time with up to 70% lamp power saving. Press any key on the projector or remote control to restore the image. The word "Eco Blank"...

  • Page 40: Adjusting The Sound

    Adjusting the sound The sound adjusents made as below will have an effect on the projector speaker(s). Be sure you have made a correct connection to the projector audio input. See "Connection" on page 19 for how the audio input is connected. Muting the sound To adjust the sound level, press on the...

  • Page 41: Personalizing The Projector Menu Display

    To unlock the keys, press and hold on the projector or remote control for 3 seconds. Personalizing the projector menu display The On-Screen Display (OSD) menus can be set according to your preferences. The following settings do not affect the projection settings, operation, or performance. •...

  • Page 42: Shutting Down The Projector

    Shutting down the projector Press POWER on the projector or OFF on the remote control and a confirmation message displays prompting you. If you don't respond in a few seconds, the message will disappear. Press POWER on the projector or OFF on the remote control a second time.

  • Page 43: Menu Operation

    Menu operation Menu system Please note that the on-screen display (OSD) menus vary according to the signal type selected. Basic menu Sub-menu Options Off/Light Yellow/Pink/Green/ Wall Color Blue Projector Front/Front Ceiling/Rear/Rear Position Ceiling Test Pattern Off/On Auto Source On/Off Search Menu Type Basic/Advanced HDMI Range...
  • Page 44 Advanced menu Supported functions in each vary by different input sources. The un-suported functions will be gray out. Advanced Sub-menu Options menu Bright/Vivid TV/Cinema/Sport/ Picture Mode User 1/User 2/3D Load Settings Bright/Vivid TV/Cinema/Sport/ From User 1/User 2 User Mode Management Rename User Mode Brightness...
  • Page 45 Auto /4:3 /16:9/Wide/Letter Aspect Ratio Off/Light Yellow/Pink/Green/ Wall Color Blue Image Position Overscan Adjustment Display H. Size Phase PC Tuning Auto (Only for RGBHD PC Timing) Auto/3D Off/Frame Sequential/ 3D Mode Frame Packing/Top-Bottom/ Side-by-Side 3D Sync Invert Operation 45...
  • Page 46 Language Background Black/Blue/Purple Color Splash Screen BenQ/Black/Blue Projector Front/Front Ceiling/Rear/Rear Position Ceiling Disable/5 min/10 min/15 min/20 Auto Off min/25 min/30 min System Direct Power Setup: Basic Off/On Menu Type Basic/Advanced Center/Top-Left/Top-Right/ Menu Position Bottom-Right/Bottom-Left Menu Settings Menu Display Always On/5 secs/10 secs/15...
  • Page 47 Reset Lamp Reset/Cancel Timer Lamp Settings Lamp Usage Time Lamp Timer Equivalent Lamp Hour HDMI Settings HDMI Range Auto/Full/Limited 9600/14400/19200/38400/ Baud Rate 57600/115200 Test Pattern Off/On Closed Caption On/Off Closed Enable System Caption Setup: Caption Version CC1/CC2/CC3/CC4 Advanced Quick Cooling Off/On High Altitude On/Off...
  • Page 48 Description of each menu • The default values listed in this manual, especially on pages 48-57, are for reference only. They may vary between the projectors due to the continuous improvement to the products. FUNCTION DESCRIPTION Corrects the projected picture’s color when the projection Wall Color surface is not white.
  • Page 49 FUNCTION DESCRIPTION Returns all settings to the factory preset values. The following settings will reset to default: Aspect Ratio, Wall Color, Image Position, Overscan Adjustment, PC Reset All Tuning, 3D, Language, Background Color, Splash Screen, Settings Auto Off, Direct Power On, Menu Settings, Auto Source Search, HDMI Settings, Baud Rate, Test Pattern, Closed Caption, Quick Cooling, High Altitude Mode and Key Lock.
  • Page 50 Pre-defined picture modes are provided so you can optimize your Picture Mode projector image set-up to suit your program type. See "Selecting a picture mode" on page 33 for details. "Adjusting the sound" on page 40 for details. Volume "Muting the sound" on page 40 for details.
  • Page 51 FUNCTION DESCRIPTION Pre-defined picture modes are provided so you can optimize your Picture Mode projector image set-up to suit your program type. See "Selecting a picture mode" on page 33 for details. Selects a picture mode that best suits your need for the image quality and further fine-tune the image based on the selections listed on the same page below.
  • Page 52 FUNCTION DESCRIPTION "Muting the sound" on page 40 for details. Mute "Adjusting the sound" on page 40 for details. Volume "Turning off the Power On/Off Ring Tone" on page 40 Power On/Off details. Ring Tone Returns Audio menu to the factory preset values. Reset Audio Settings Operation...
  • Page 53 FUNCTION DESCRIPTION There are four options to set the image's aspect ratio depending Aspect Ratio on your input signal source. See "Selecting the aspect ratio" on page 31 for details. Corrects the projected picture’s color when the projection Wall Color surface is not white.
  • Page 54 Black, Blue, or Purple. Allows you to select which logo screen will display during Splash Screen projector start-up. Four options are available: BenQ logo, Black, or Blue. The projector can be installed on a ceiling or behind a screen, or Projector with one or more mirrors.
  • Page 55 FUNCTION DESCRIPTION Reset Lamp Timer "Resetting the lamp timer" on page 63 for details. Lamp Settings Lamp Timer "Getting to know the lamp hour" on page 59 for details on how the total lamp hour is calculated. Selects an input source type for the HDMI signal. Auto Enables the auto selection of HDMI format.
  • Page 56 FUNCTION DESCRIPTION Selecting On enables the function and the projector cooling time will be shortened to a few seconds. Quick Cooling If you attempt to restart the projector right after the quick cooling process, it may not be turned on successfully and will rerun its cooling fans.
  • Page 57 FUNCTION DESCRIPTION Shows the current signal source. Source Shows the selected mode in the Picture menu. Picture Mode Shows the native resolution of the input signal. Resolution Shows input system format RGB or YUV. Color System Displays the number of hours the lamp has been used. Lamp Usage Time Shows the current 3D mode.

  • Page 58: Maintenance

    Maintenance Care of the projector Your projector needs little maintenance. The only thing you need to do on a regular basis is to keep the lens and case clean. Never remove any parts of the projector except the lamp. Contact your dealer if other parts need replacing.

  • Page 59: Lamp Information

    Lamp information Getting to know the lamp hour When the projector is in operation, the duration (in hours) of lamp usage is automatically calculated by the built-in timer. The method of calculating the equivalent lamp hour is as follows: Lamp Usage Time = (x+y+z) hours, if Time used in Normal mode = x hours Time used in Eco mode = y hours Time used in SmartEco mode = z hours...
  • Page 60 The lamp modes are defined as the chart below. Lamp Power Description Normal Provides full lamp brightness Lowers brightness to extend the lamp life and decreases the Economic fan noise Adjusts the lamp power automatically depending on the SmartEco content brightness level Setting Auto Off This function allows the projector to turn off automatically if no input source is detected after a set period of time to prevent unnecessary waste of lamp life.
  • Page 61 Timing of replacing the lamp When the Lamp indicator lights up red or a message appears suggesting it is time to replace the lamp, please install a new lamp or consult your dealer. An old lamp may cause a malfunction in the projector and in some instances the lamp may explode. Do not attempt to replace the lamp yourself.
  • Page 62 • To assure optimal performance from the projector, it is recommended that you purchase a BenQ projector lamp for lamp replacement. • Ensure good ventilation when handling broken lamps. We recommend that you use respirators, safety glasses, goggles or face shield and wear protective clothing such as gloves.
  • Page 63 Remove the lamp cover by (a) sliding the cover toward the side of the projector and (b) lifting it off. • Do not turn the power on with the lamp cover removed. • Do not insert your fingers between the lamp and the projector.
  • Page 64 Replace the lamp cover by sliding it into place. 10. Tighten the screw that secures the lamp cover. • Loose screw may cause a bad connection, which could result in malfunction. • Do not over tighten the screw. 11. Restart the projector. Do not turn the power on with the lamp cover removed.
  • Page 65 Indicators Light Status & Description POWER TEMP LAMP System Message Orange Stand-by mode Green Powering up Flashing Green Normal operation Orange Normal power-down cooling Flashing Download Flashing Flashing Flashing Green CW start fail Burn-In Messages Green Burn-in ON Green Green Green Burn-in OFF Lamp Error Messages Lamp1 error in normal operation...

  • Page 66: Troubleshooting

    Troubleshooting The projector does not turn on. Cause Remedy Plug the power cord into the AC inlet on the There is no power from the power projector, and plug the power cord into the cable. power outlet. If the power outlet has a switch, make sure that it is switched on.

  • Page 67: Specifications

    Please visit below website and choose 9 pin x 1 your country to find your service contact IR receiver x 1 window. USB mini-B x 1 http://www.benq.com/welcome Lamp life results will vary depending on environmental conditions and usage. Specifications 67...

  • Page 68: Dimensions

    Dimensions 332.4 mm (W) x 99 mm (H) x 241.3 mm (D) 332.4 Ceiling mount installation Ceiling mount screw: M4 (Max L = 25 mm; Min L=20 mm) Unit: mm 60.6 89.1 166.2 332.4 Specifications...

  • Page 69: Timing Chart

    1024 x 768 XGA_85 84.997 68.667 94.500 XGA_120 (Reduce 119.989 97.551 115.5 ◎ Blanking) 1152 x 1152 x 864 67.5 864_75 BenQ 1024 x 576 Notebook 35.82 46.966 Timing BenQ 1024 x 600 Notebook 64.995 41.467 51.419 Timing 1280 x 74.250 ◎...
  • Page 70 XGA_85 84.997 68.667 94.500 XGA_120 (Reduce 119.989 97.551 115.5 ◎ Blanking) 1152 x 1152 x 864 67.5 864_75 BenQ 1024 x 576 Notebook 35.82 46.966 Timing BenQ 1024 x 600 Notebook 64.995 41.467 51.419 Timing 1280 x 1280 x 720 74.250...
  • Page 71 WXGA_60 59.81 49.702 83.500 ◎ ◎ ◎ WXGA_75 74.934 62.795 106.500 WXGA_85 84.88 71.554 122.500 1280 x 800 WXGA_120 (Reduce 119.909 101.563 146.25 ◎ Blanking) SXGA_60 60.02 63.981 108.000 ◎ ◎ 1280 x 1024 SXGA_75 75.025 79.976 135.000 SXGA_85 85.024 91.146 157.500 1280 x...
  • Page 72 1080/60i 1920 x 1080 33.75 74.25 ◎ 1080/24P 1920 x 1080 74.25 ◎ ◎ ◎ 1080/25P 1920 x 1080 28.13 74.25 1080/30P 1920 x 1080 33.75 74.25 1080/50P 1920 x 1080 56.25 148.5 ◎ ◎ 1080/60P 1920 x 1080 67.5 148.5 ◎...

  • Page 73: Warranty And Copyright Information

    Proof of purchase date will be required with any warranty claim. In the event this product is found to be defective within the warranty period, BenQ's only obligation and your exclusive remedy shall be replacement of any defective parts (labor included).
