La Marzocco linea classic Installation Manuallines

U.S. installation guideline
linea
classic

Dimensions

Height
Width
Depth
Working Height°

Weights

Shipping Weight
Operating Weight

Power

Voltage/Phase/Cycle
Wattage
Full Load Amp Draw
Max. Dist. from Outlet*
NEMA Plug and Outlet*

Water

Water Flow Rate
Dynamic Water Pressure †
Min. Pipe Size Diameter*
Water Connection*
Water Quality
* suggested | † regulate as needed
° Height from the base of the machine to the group head
1 group
21"
20"
22"
13.5"
145.5 lbs
138.8 lbs
208-240 VAC 1Φ 60Hz
2500
12
5'
6-20P; 6-20R

Drainage

2GPM Max. Dist.*
45PSI Drain Slope*
3/8"
3/8" male comp.
Contact us for a free water test kit. See water specifications.
| ‡ This machine must be installed in accordance with the applicable federal, state and local plumbing codes
2 group
21"
28"
22"
13.5"
174.2 lbs
189.5 lbs
208-240 VAC 1Φ 60Hz
4600
22
5'
6-30P; 6-30R
5'
Min. 1/4" per foot
‡
3 group
21"
37"
22"
13.5"
218.3 lbs
238.0 lbs
208-240 VAC 1Φ 60Hz
6100
28
5'
6-50P; 6-50R

External Pump

Dimensions
Max. Dist. from Water Supply* 4'
Max. Dist. from Machine
Counter Hole Diameter
4 group
21"
46"
22"
13.5"
269.0 lbs
301.9 lbs
208-240 VAC 1Φ 60Hz
8000
37
5'
6-50P; 6-50R
12" × 12" × 12"
8'
2.5"
